- Page 1 User's Manual SPP-R200 Mobile Printer Rev. 1.01 http://www.samsungminiprinters.com...
-
Page 2: Table Of Contents
3-8 Control Panel Usage················································································· 17 3-9 MSR Usage·······························································································18 4. Self-Test··············································································································18 5. Peripherals Connection ···················································································· 20 5-1 Bluetooth Connection················································································ 20 5-2 Interface Cable Connection ······································································ 20 6. Printer Cleaning································································································· 21 7. Appendix ············································································································22 7-1 Specifications ····························································································22 7-2 Certification ······························································································· 23 7-3 Label Types·······························································································23 Rev. 1.01... -
Page 3: Manual Information & Usage Precautions
■ Manual Information ※ Manual Information & Usage Precautions This user manual contains basic information for product usage as well as for emergency measures that may be required. ※ The following separate manuals provide more detailed content on various technological issues and areas. -
Page 4: Safety Precautions
PROHIBIT Do not pull the cable to unplug. • This can damage the cable, which is the origin of a fire or a breakdown of the printer. PROHIBIT Do not plug in or unplug with your hands wet. • You can be electrocuted. - Page 5 • After the disappearance of the smoke, call your dealer to repair it. TO UNPLUG PRINTER Install the printer on the stable surface. • If the printer falls down, it can be broken and you can hurt yourself. PRINTER PROHIBIT Do not let water or other foreign objects in the printer.
-
Page 6: Battery Safety Precautions
■ Battery Safety Precautions Make sure to review the user manual carefully prior to product use. Neglecting to heed the following instructions can result in battery overheating, combustion, explosion, damage and/or decline in performance and product life. Danger 1. Do not allow water, seawater, etc. enter or leak into the battery interior. If the safety mechanism within the battery becomes burned out, any charging of the battery can result in abnormal electrical current flow and/or voltage that causes an abnormal chemical reaction, which may then cause the battery to overheat, ignite, and/or explode. - Page 7 10. Do not pierce the battery with a sharp object, such as a nail, or hit it with a heavy object, such as a hammer, and take care not to step on the battery. The battery may rupture or become warped, causing short circuits within that may result in battery overheating, combustion, and/or explosion.
- Page 8 Caution 1. Do not use or leave the battery in a location exposed to high temperatures or intense direct sunlight, such as within an automobile. Doing so can cause battery overheating and/or combustion. In addition, battery performance and product life may be reduced. 2.
-
Page 9: Other Precautions
Recommended 1. Review the user manual for instructions concerning insertion/removal of batteries into/from the product. 2. As the battery is slightly charged upon factory shipment, use it to confirm proper product operation upon purchase. If product operation cannot be confirmed or longer use of the product is required, use the exclusive charger to charge the battery. -
Page 10: Content Confirmation
SPP-R200 1. Content Confirmation The following items should all be contained in the printer package. Contact the dealer from which the purchase was made if any item is damaged and/or missing. SPP-R200 Battery Battery Charger Power Cord Belt Strap Cleaning Pen... -
Page 11: Product Part Names
2. Product Part Names • Front Power Button Paper Feed Button MSR Cover • Rear Belt Strap Hole Cable Connector Rev. 1.01 Paper Cover BT Cap (Bluetooth Download Connector) Battery Power Connector - 11 - SPP-R200 Open Button... -
Page 12: Installation & Usage
4) Plug the power cord② into an electrical outlet. ② CAUTION The printer may incur serious damage if the battery charger provided by BIXOLON is not used. BIXOLON is not legally liable for any such damages. (The voltage and electrical current specifications of the printer and battery charger must match.) -
Page 13: Battery Holder (Optional) Usage
4) Insert the battery④ into the battery holder③ until a snapping sound is heard. 1) Connect the cigarette lighter jack charger① to the cigarette lighter jack of an automobile and/or the printer or ② battery holder② as shown in the image. - 13 - SPP-R200... -
Page 14: Paper Installation
3) Take care to align the paper correctly. 4) Pull the paper out as shown in the image and close the paper cover. 5) Tear off any excess paper in the direction of the side of the printer. - 14 - SPP-R200... -
Page 15: Belt Strap Usage
3-6 Belt Strap Usage Belt Strap Coin Belt Belt Rev. 1.01 1) Insert the belt strap screw into the belt strap hole. 2) Use a coin to tighten the belt strap screw as shown in the image. 3) Undo the belt strap Velcro. 4) Fasten the belt strap to a belt. -
Page 16: Leather Case (Optional) Usage
3-7 Leather Case (Optional) Usage Rev. 1.01 1) Undo the Velcro. 2) Place the printer into the leather case following the direction shown in the image. 3) Close the Velcro. 4) Affix to a belt using the clip at the rear of the case. -
Page 17: Control Panel Usage
1) If the green lamp turns on in unison with the battery status lamp, the printer can be used with Bluetooth wireless communication. 2) If only the green lamp is lit, the printer has entered the power saving mode. NOTE The power saving mode is activated after the first communication, with the default time interval being 10 seconds. -
Page 18: Msr Usage
Run the self-test when first setting the printer or when encountering a problem, and check the following. - Control Circuit, Mechanisms, Print Quality, ROM Version, and Memory Switch Settings If no issue is found with the printer after running the self-test, examine the other devices or peripherals and software. software. - Page 19 Handshaking : DTR/DSR Default Codepage : PC437 Print Speed : 80mm/s Double byte character mode:On Busy printer buffer full Font : 12 x 24 Paper out Bell : On Low Battery Buzzer : On Power off time : 15 Min...
-
Page 20: Peripherals Connection
2) Connect the interface cable to the USB port of the device (PDAs, PCs, etc.). NOTE The interface cable that can be connected with the printer is available in both USB and Serial type. Refer to the service manual for detailed interface cable specifications. -
Page 21: Printer Cleaning
3) Use a cloth moistened with an alcohol solution to clean the paper sensor are and remove any paper remnants and/or dust. 4) Insert paper into the printer 1~2 minutes after completing the cleaning process and close the printer cover. -
Page 22: Appendix
79.5mm × 126.7mm × 43.6mm (3.13″ × 4.99″ × 1.72″) Printer: 184g (0.41lbs) Printer + Battery: 236g (0.52lbs) Printer + Battery + Paper: 293g (0.65lbs) Package: approx. 680g (1.5lbs) Battery, Battery Charger, Belt Strap, Cleaning Pen Battery, Battery Holder, Leather Case,... -
Page 23: Certification
• North America: FCC rules part 15C • Safety Standards: CB-scheme: IEC60950-1: 2001 WARNING Use of an unprotected interface cable with this printer conflicts with EMC standards. Users should only use cables approved by BIXOLON. 2) CE Mark • EMC Directive 89/336/EEC •...
