Installing a CD-ROM Drive

3-20 Upgrading the Computer
To install an optional Compaq Slimline 24X Max CD-ROM
drive:
1. Install two guide screws on each side of the drive.
All screws are shoulder-head screws.
Installing Guide Screws in the CD-ROM Drive
2. Position the guide screws on the drive into the J-slots in the
drive bay. Slide the drive toward the front of the computer.
Ensure that the spring-loaded locking lever properly
secures the drive.
