16 Channel Digital Output Data Acquisition
Product Website:
http://www.icpdas-usa.com/i_7043_i_7043d.html
http://www.icpdas-usa.com/dcon_utility_pro.html
1. Introduction
The I-7043 offers 16 digital output channels, each of which are non-isolated
and support sink-type output using an open collector. There are also
options to enable both power-on and safe values. The I-7043D has 16 LED
indicators that can be used to monitor the status of DO channels. The
hardware specifications for the M-7043 are the same as the I-7043, and
both support the Modbus RTU and DCON protocols, which can be
configured via software.
2. Terminal Assignment
I-7043
16 Ch DO DAQ Module- QuickStart (Jan/2017)
ICP DAS USA, Inc. |
www.icpdas-usa.com
I-7043
Module
Quick Start Guide
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
