- Page 1 REDMOND / MANSFIELD / STANWICK COFFEE TABLE MODEL # 3AXCADM-01 1/14...
- Page 3 ENTER TO WIN www.facebook.com/simplihomefurnishings...
-
Page 4: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CARE and MAINTENANCE... - Page 5 PART DESCRIPTION NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST) 5/14...
-
Page 6: Hardware Description
HARDWARE DESCRIPTION 6/14... - Page 7 COMPONENTS-KEY DIAGRAM MODEL # 3AXCADM-01...
- Page 8 ASSEMBLY MODEL # 3AXCADM-01 1. Attach four Cam Lock Pins 3 to back of Drawer Front E . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides F . 3. Insert two Cam Locks 3 into pre-drilled holes on each Drawer Side F . 4.
- Page 9 ASSEMBLY MODEL # 3AXCADM-01...
- Page 10 ASSEMBLY MODEL # 3AXCADM-01 1. Attach three Cam Lock Pins 3 to each Side A using guide holes. 2. Align Cam Lock Pins with pre-drilled holes on Bottom Shelf C . 3. Insert six Cam Locks 3 into pre-drilled holes on Bottom Shelf C . 4.
- Page 11 ASSEMBLY MODEL # 3AXCADM-01 1. Attach Top B to Sides A and Dividers D using twelve Allen Key Screws 1 (three screws on each Side and Divider). 2. Use Allen Key 2 to tighten screws. Do not over-tighten.
- Page 12 ASSEMBLY MODEL # 3AXCADM-01 1. Insert assembled drawers into glides on assembled table.
-
Page 13: Warranty
WARRANTY...
