- Page 1 ARTISAN / HOLDEN / STRATFORD BEDSIDE TABLE MODEL # 3AXCART-02 1/14...
- Page 2 FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli-home.com/customer-support PLEASE ENSURE TO HAVE THE MODEL # FROM THE PACKAGING OR INSTRUCTION BOOKLET TO RETURN THE PRODUCT: PLEASE CONTACT THE RETAILER WHERE THE ITEM WAS PURCHASED FROM 2/14...
- Page 3 ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.com/simplihomefurnishings 3/14...
-
Page 4: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # 3AXCART-02 PARTS DESCRIPTION SHELF BOTTOM SHELF QTY 1 QTY 1 QTY 1 SIDE BACK PANEL DRAWER FRONT QTY 1 PAIR QTY 1 SET QTY 1 DRAWER SIDE DRAWER BACK DRAWER BOTTOM QTY 1 PAIR QTY 1 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. - Page 6 PRE-ASSEMBLY INFORMATION MODEL # 3AXCART-02 HARDWARE DESCRIPTION HANDLE CAM LOCK PIN ALLEN KEY BOLT ALLEN KEY SCREW M4 X 25 mm M6 X 30 mm M6 X 30 mm CAM LOCK QTY 1 SET QTY 8 QTY 4 QTY 4 SETS Required - Flathead screwdriver PHILLIPS SCREW...
- Page 7 COMPONENTS – KEY DIAGRAM MODEL # 3AXCART-02 7/14...
- Page 8 ASSEMBLY MODEL # 3AXCART-02 STEP 1 1. Attach 4 Cam Lock Pins 3 to pre-drilled holes at back of Drawer Front F . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides G . 3. Insert 2 Cam Locks 3 into pre-drilled holes on each Drawer Side G . 4.
- Page 9 ASSEMBLY MODEL # 3AXCART-02 STEP 3 1. Align Drawer Back H with Drawer Bottom I and press firmly into slot . 2. Attach Drawer Back using 2 Allen Key Screws 2 through pre-drilled holes on each Side G . 3. Use Allen Key 6 to tighten screws. Do not over-tighten. STEP 4 NOTE: The screwdriver is not included in the hardware pack.
- Page 10 ASSEMBLY MODEL # 3AXCART-02 STEP 5 1. Insert 6 Dowels 5 into pre-drilled holes on Shelf C . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. ½ length of Dowels should be exposed. 3. Align pre-drilled holes on Sides D with Dowels 5 on Shelf C . 4.
- Page 11 ASSEMBLY MODEL # 3AXCART-02 STEP 6 1. Attach Top A to Sides D using 4 Allen Key Bolts 1 ( 2 Bolts / each Side ). 2. Use Allen Key 6 to tighten bolts. Do not over-tighten. 11/14...
- Page 12 ASSEMBLY MODEL # 3AXCART-02 STEP 7 1. Attach Back Panel E to back frame of cabinet using Phillips Screws Round Head 7 through pre-drilled holes. 2. Use Phillips screwdriver to tighten screws. STEP 8 1. Insert assembled drawers into glides on assembled table. 12/14...
-
Page 13: Warranty
WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights. - Page 14 Question, problems, missing parts? Before returning your product please email Customer Support at simpli-home.com/customer-support or call Customer Support at 1-866-518-0120 ext. 262 Monday to Friday between 9 am – 4 pm EST For more information visit us on our website www.simpli-home.com Like us on facebook www.facebook.com/simplihomefurnishings...
