- Page 1 S IMP H O M E L I F E B Y D E S I G N RIVERSIDE / LAWSON / CAYLEY COFFEE TABLE MODEL # 3AXCRIV-01 1/13...
- Page 2 FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli-home.com/customer-support PLEASE ENSURE TO HAVE THE MODEL # FROM THE PACKAGING OR INSTRUCTION BOOKLET TO RETURN THE PRODUCT: PLEASE CONTACT THE RETAILER WHERE THE ITEM WAS PURCHASED FROM 2/13...
- Page 3 L I F E B Y D E S I G N ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.com/simplihomefurnishings 3/13...
-
Page 4: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 5: Pre-Assembly Information
MODEL # 3AXCRIV-01 PRE-ASSEMBLY INFORMATION BOTTOM SHELF QTY 1 QTY 2 QTY 1 MODEL # 3AXCRIV-01 ALLEN KEY BOLT ALLEN KEY LOCK WASHER M8 X 20 mm QTY 1 QTY 12 QTY 12 WASHER Ø20 mm QTY 12 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. - Page 6 MODEL # 3AXCRIV-01 6/13...
- Page 7 MODEL # 3AXCRIV-01 STEP 1 1. Align one Leg B to Top A by matching the letters P1 to P1 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Top A and Leg B . 3.
- Page 8 MODEL # 3AXCRIV-01 STEP 2 1. Align other Leg B to Top A by matching the letters P2 to P2 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Top A and Leg B . 3.
- Page 9 MODEL # 3AXCRIV-01 STEP 3 1. Place coffee table assembly on its side on a flat smooth surface. 2. Slide Bottom Shelf C in leg slots. 9/13...
- Page 10 MODEL # 3AXCRIV-01 STEP 4 1. Align Bottom Shelf C to Leg B by matching the letters P1 to P1 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Leg B and Bottom Shelf C . 3.
- Page 11 MODEL # 3AXCRIV-01 STEP 5 1. Align Bottom Shelf C to other Leg B by matching the letters P2 to P2 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Leg B and Bottom Shelf C .
-
Page 12: Warranty
L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. - Page 13 S IMP H O M E L I F E B Y D E S I G N Question, problems, missing parts? Before returning your product please email Customer Support at simpli-home.com/customer-support or call Customer Support at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
