Sunjoy L-AW001-R Beauty-Mark Manual Retractable Awning
-Red Strip
Owner's Manual
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569
from 8:00 a.m. EST to 8:00 p.m. PST. You can also send the email to
amazon@sunjoygroup.com
or visit
www.sunjoyonline.com
to get tech. assistance or to place your
replacement part order form.
Advertisement
Table of Contents
Related Manuals for Sunjoy L-AW001-R
Summary of Contents for Sunjoy L-AW001-R
- Page 1 -Red Strip Owner’s Manual IMPORTANT Thank you very much for choosing Sunjoy Group. Please take time to read these instructions thoroughly and follow each step carefully for safe and easy operation. Keep this manual for future reference. We would like to hear from you with any comments or suggestions. You can call us toll-free at 1-866-578-6569 from 8:00 a.m.
- Page 2 Cautions: 1. Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area of gazebo construction. 2. For your safety, Do not assemble this item alone. Two people are recommended for safe assembly. 3.
- Page 3 Step 1: Installation of Wall Bracket Square bar screw Square bar screw Wooden Concrete Wall Wall Notice: Please call a professional for assistance on installation for walls other than wood or concrete. Step.1 : Open packaging, remove wall bracket (B), and anchor bolt (DD), to install on wall or ceiling. Place anchors bolt (DD) or Hex Sharp bolt (EE) into the holes, install the wall bracket and keep all brackets level, and tightly fasten screws.
- Page 4 Step 3: Awning Operation Fig.1: Fabric Cover Cover Cover Correct way Wrong way Fig.2: Open and close manual-operated awning Put the crank handle into gear box loop, Place hands on plastic handle and turn handle clockwise to open awning. Plastic Handle Wrong way Correct way Notice:...
- Page 5 Care & Maintenance: Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling &...
