Sunjoy L-GZ717PST-C-PK Assembly Instruction

10x12ft windsor dome gazebo-canopy

10x12ft Windsor Dome Gazebo-Canopy

Assembly Instruction

Item no# L-GZ717PST-C-PK

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble

or install the product.

WARNING

Keep all children and pets away from assembly area. Children and pets should

be supervised when they are in the area.

Keep all flame and heat sources away from the tent fabric. This tent is made

with fabric that meets CPAI-84 specification for flame resistance. It is not

fireproof. The fabric will burn if left in continuous contact with any flame

sources. The application of any foreign substance to the tent fabric may render

the flame-resistant properties ineffective.

Before beginning assembly of product, make sure all parts are present.

Compare parts with package contents list. If any part is missing or damaged,

do not attempt to assemble the product.

Table of Contents

Do you have a question about the L-GZ717PST-C-PK and is the answer not in the manual?

Page 1 10x12ft Windsor Dome Gazebo-Canopy Assembly Instruction Item no# L-GZ717PST-C-PK SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble or install the product. WARNING Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area.
Page 2 Parts List Small canopy 1 pc Big Canopy 1 pc Fig.1: Open the hook-and-loop fasteners at the valance of canopy. Fig.2: Remove four corners of the canopy from cant beam (H1) and take down the canopy. Fig.3: Take down the small top from big top. Fig.4: Remove the finial (L) from the small top.
Page 3 Fig.5: Open the hook-and-loop fastener at the netting of small top Fig.6: Remove the small canopy (R) from small top cant beam and take it down. Fig.7: Take down the big canopy (S) from big top. Fig.1: Put the small canopy (R) onto the small top, and then fix the finial (L) to the small top.
Page 4 Fig.3: Fix the hook-and-loop fasteners of the netting of small canopy (R). Fig.4: Put the big canopy (S) onto the big top and do not spread out. Fig.5: Fix the small top to the big top by inserting the tube of the small top cant beam (J) into the tube of big top cant beam (D1).
Page 5 Please do not return this product to the store. For technical assistance or replacement parts, please call Sunjoy Group at 1 (866) 578-6569 between 8:00 AM EST and 8:00 PM PST. You may fax your replacement parts form (which is...
