05/20
Product Code: 2015
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
BOTTLE JACK
Specifications
• Safe Working Capacity: 12,000kg
• Hydraulic Lift: 100mm
• Adjustable Height: 70mm
• Minimum Height: 180mm
• Maximum Height: 350mm
• Base Area: 157 x 134mm
• Handle: 500 x 20mm
• Carton: 148 x 142 x 190mm (plus handle)
• Gross Weight: 7kg
With
proven
and
Product Code: 2015
HYDRAULIC
trusted "Made
for
the
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 2015
Summary of Contents for TradeQuip 2015
- Page 1 • Handle: 500 x 20mm • Carton: 148 x 142 x 190mm (plus handle) • Gross Weight: 7kg About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
- Page 2 Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the TradeQuip policy of continuous improvement determines the right to make modifications without prior warning.
- Page 3 Product Code: 2015 STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating...
- Page 4 ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE 1. FEATURES The TradeQuip Hydraulic Bottle Jack is designed specifically for lifting and lowering, but not sustaining load. This unit provides enough lifting power for use with most automotive and farm vehicles, heavy duty machinery, industrial construction equipment and more.
- Page 5 Product Code: 2015 4. MAINTENANCE If you use and maintain your equipment properly, it will give you many years of service. Follow the maintenance instructions carefully to keep your equipment in good working condition. Never perform any maintenance on the equipment while it is under a load.
- Page 6 Product Code: 2015 PARTS LIST Part # Description Part # Description Adjustable Saddle Ball 6mm Saddle Socket Ball Stopper Piston Rod Base Bolt O-Ring (Nut) Washer (Pump) Seal Pump Piston O-Ring (Plunger) Bowl Washer Back Ring O-Ring (Piston) Plunger Cylinder...
- Page 7 Product Code: 2015 TROUBLESHOOTING Problem Symptom Cause Conclusion Solution Jack will not Pump has resistance Release valve not Bypass through release Ensure release lift but no lift tightly closed valve valve tightly closed Pump has no resistance and/or lift Air in hydraulic system...
- Page 8 WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
