TradeQuip 2829 Owner's Manual

35,000kg air actuated garage jack
Hide thumbs

Advertisement

Quick Links

Download this manual
Mar-18
Product Code: 2829
OWNER'S MANUAL
PRODUCT CODE: 2829
35,000kg AIR ACTUATED GARAGE JACK
Max Lift
Min Lift
Operating Air
Lifting Capacity
Weight
Height
Height
Pressure
35,000kg
493mm
245mm
100-120psi
46kg
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2829 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TradeQuip 2829

Summary of Contents for TradeQuip 2829

  • Page 1 Mar-18 Product Code: 2829 OWNER’S MANUAL PRODUCT CODE: 2829 35,000kg AIR ACTUATED GARAGE JACK Max Lift Min Lift Operating Air Lifting Capacity Weight Height Height Pressure 35,000kg 493mm 245mm 100-120psi 46kg Made in China to TQB Brands Pty Ltd specifications...
  • Page 2 Mar-18 Product Code: 2829 Made in China to TQB Brands Pty Ltd specifications Visit us at www.tqbbrands.com.au...

  • Page 3: Table Of Contents

    Mar-18 Product Code: 2829 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.

  • Page 4: Warning

    Mar-18 Product Code: 2829 SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY  Support load by appropriate means after  Only lift areas of the vehicle designated by lifting the vehicle manufacturer.

  • Page 5: Assembly, Operation, Preventitive Maintenance

    ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The TradeQuip Air Actuated Garage Jack utilises compressed air to activate a booster cylinder, to move hydraulic oil within the cylinder up & down. It adopts a heavy duty hydraulic design combination of compressed air and hydraulic pressure, to create, strong jacking capacity and low lifting clearance in one jack.
  • Page 6 Mar-18 Product Code: 2829 Air/hydraulic pump prime instructions: The air/hydraulic pump may lose its prime during shipment or after long periods without use. To prime the pump, follow these steps; Remove the upper cover. Loosen the hex socket bolt one-half turn (see figure1) Close the release valve.
  • Page 7 Mar-18 Product Code: 2829 4. OPERATION This jack is equipped with a handle position lock. To adjust the handle, release the lock device by pulling the lever up. The lever is spring loaded so, so it should lock into the desired position.
  • Page 8 Mar-18 Product Code: 2829 5. INSPECTION  Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts.  The jack shall always be maintained in accordance with the maintenance instructions (Section 7).
  • Page 9 Mar-18 Product Code: 2829 7. MAINTENANCE Monthly maintenance is recommended. Lubrication is critical to jacks as they support heavy loads. Any restriction due to dirt, rust, etc, can cause either slow movement or cause extremely rapid jerks damaging the internal components. The following steps are designed to keep the jack well maintained and operational.

  • Page 10: Troubleshooting

    Mar-18 Product Code: 2829 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Jack will not lift Control valve in wrong position. Turn control valve knob Low/no oil in reservoir. clockwise. Air-locked system. Fill with oil and bleed system. Load is above capacity of jack.
  • Page 11 Mar-18 Product Code: 2829 Part # Description Part # Description Cover Release Valve Rod Coping Screw Gimbal Bushing Right Wallboard Spring Hunger Snap Ring Left Wallboard O-Ring Bolt M6x12 Bushing Washer 12 O-Ring Spring Washer 12 Piston Rod Bolt M12x25...

  • Page 12: Parts List

    Mar-18 Product Code: 2829 PARTS LIST Made in China to TQB Brands Pty Ltd specifications Page 12 Visit us at www.tqbbrands.com.au...

  • Page 13: Warranty

    Product Code: 2829 WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
