AIR/HYDRAULIC
Specifications:
• Safe Working Capacity: 12,000kg
• Minimum Height: 260mm
• Maximum Height: 510mm
• Hydraulic Stroke: 170mm
• Screw Extension Height: 80mm
• Operating Air Pressure: 110-125psi
• Air Fitting: 1/4"
• Carton: 250x180x270mm
• Gross Weight: 12.75kg
With
proven
and
Product Code: TQBJ12TA
BOTTLE JACK
trusted "Made
for
the
Advertisement
Table of Contents
Related Manuals for TradeQuip TQBJ12TA
Summary of Contents for TradeQuip TQBJ12TA
- Page 1 • Screw Extension Height: 80mm • Operating Air Pressure: 110-125psi • Air Fitting: 1/4" • Carton: 250x180x270mm • Gross Weight: 12.75kg About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
-
Page 2: Table Of Contents
Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the TradeQuip policy of continuous improvement determines the right to make modifications without prior warning. - Page 3 Product Code: TQBJ12TA STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating...
-
Page 4: Assembly, Operation & Preventative Maintenance
ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE 1. FEATURES The TradeQuip Air Actuated Hydraulic Bottle Jack is designed to operate either manually or pneumatically for lifting and lowering, but not sustaining load. This 12,000kg Heavy-Duty Air/Hydraulic Bottle Jack is the perfect choice for a wide variety of uses. - Page 5 Product Code: TQBJ12TA Bleed Air for Air Motor: Lift Saddle 1. Remove the Oil Filler Bung and if required, refill with *32 Grade hydraulic oil until the oil is Oil Filler Hole lapping the bottom of the Oil Filler Hole.
- Page 6 Product Code: TQBJ12TA To Lower Vehicle: 1. Raise load high enough to allow clearance for the jack stands to be removed, then carefully remove jack stands. 2. Insert handle release valve and slowly turn handle counter clockwise, no more then 1/2 a turn.
-
Page 7: Parts List
Product Code: TQBJ12TA PARTS LIST Part Description Part Description Base Back-up Ring Ball 1/4" Piston Seal Release Valve R-Pin Ball Cup Connector Spring Handle Bracket Spring Lock Lever Screw Lever Nylon Ring Cylinder O-Ring O-Ring O-Ring Cup Seal Packing Throttle... -
Page 8: Troubleshooting
Product Code: TQBJ12TA TROUBLESHOOTING Problem Symptom Cause Conclusion Solution Jack will not Manual pump has Release valve not Bypass through release Ensure release valve lift using no resistance, lift tightly closed valve tightly closed manual ram will not raise pump... -
Page 9: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
