TradeQuip 2820 Owner's Manual

Aluminium racing jack
Hide thumbs

Advertisement

Quick Links

Download this manual
Mar-18
Product Code: 2820
OWNER'S MANUAL
PRODUCT CODE: 2820
ALUMINIUM RACING JACK
Working
Maximum
Minimum
Gross
Net Weight
Package Size
Load Limit
Height
Height
Weight
1600kg
420mm
95mm
21kg
19.8kg
720x330x195mm
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2820 and is the answer not in the manual?

Questions and answers

Related Manuals for TradeQuip 2820

Summary of Contents for TradeQuip 2820

  • Page 1 Mar-18 Product Code: 2820 OWNER’S MANUAL PRODUCT CODE: 2820 ALUMINIUM RACING JACK Working Maximum Minimum Gross Net Weight Package Size Load Limit Height Height Weight 1600kg 420mm 95mm 21kg 19.8kg 720x330x195mm Made in China to TQB Brands Pty Ltd specifications...

  • Page 2: Table Of Contents

    Mar-18 Product Code: 2820 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.

  • Page 3: Safety Instructions

    Mar-18 Product Code: 2820 SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY  Support load by appropriate means after  Only lift areas of the vehicle designated by lifting the vehicle manufacturer.

  • Page 4: Assembly, Operation, Preventitive Maintenance

    ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The TradeQuip 1600kg Racking Jack is designed for the professional automotive service technician and automotive enthusiasts needing fast acting performance. The ultra weight aluminium design allows maximum portability. It features a single roller wheel on the front for easier manoeuvrability.
  • Page 5 Mar-18 Product Code: 2820 Lowering Be sure all tools and personnel are clear before lowering load. Slowly open the release valve! The more you turn the handle counter-clockwise, the faster the load will come down. Maintain control of the rate of speed at which the load lowers at all times! Raise load high enough to clear the jack stands.
  • Page 6 Mar-18 Product Code: 2820 Important: Use only good grade hydraulic jack oil. Avoid mixing different types of fluid and NEVER use brake fluid, turbine oil, transmission fluid, motor oil or glycerine. Improper fluid can cause premature failure of the jack and the potential for sudden and immediate loss of load.

  • Page 7: Troubleshooting

    Mar-18 Product Code: 2820 7. SERVICE & REPAIR Any jack found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge.

  • Page 8: Parts List - Power Unit Assembly

    Mar-18 Product Code: 2820 PARTS LIST - POWER UNIT ASSEMBLY Part # Description Part # Description 22-1 Stop Collar 22-20 Steel Ball 22-2 Oil Tank 22-21 Spring 22-3 Cylinder 22-22 O-Ring 22-4 Piston Rod 22-23 Release Rod Assembly 22-5 Snap Ring...

  • Page 9: Parts List - Main Body Assembly

    Mar-18 Product Code: 2820 PARTS LIST - MAIN BODY ASSEMBLY Made in China to TQB Brands Pty Ltd specifications Page 9 Visit us at www.tqbbrands.com.au...
  • Page 10 Mar-18 Product Code: 2820 Part # Description Part # Description Rear Wheel Assy Leaf Spring Rear Wheel Seat Handle Handle Washer Bolt Washer Bolt Washer Snap Ring Washer Linkage Bolt Bolt Linkage Washer Washer Shaft Bolt Shaft Handle Linkage Frame...

  • Page 11: Warranty

    Product Code: 2820 WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
