- Page 1 Product Code: 2806T OWNER’S MANUAL PRODUCT CODE: 2806T HYDRAULIC GARAGE JACK Working Maximum Minimum Gross Net Weight Package Size Load Limit Height Height Weight 3000kg 485mm 100mm 45kg 43kg 740x410x195mm Made in China to TQB Brands Pty Ltd specifications Visit us at www.tqbbrands.com.au...
-
Page 2: Table Of Contents
Product Code: 2806T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Safety Instructions
Product Code: 2806T SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY • Support load by appropriate means after • Only lift areas of the vehicle designated by lifting the vehicle manufacturer. • Do not exceed rated capacity •... -
Page 4: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The TradeQuip Hydraulic Garage Jack is designed for the professional automotive service technician and automotive enthusiasts needing fast acting performance. This 2806T professional-quality Quick Lift Low-Profile Garage Jack has a 3,000kg lift capacity and a 100mm minimum lift height for easy access under low-profile vehicles. - Page 5 Product Code: 2806T Lowering the Vehicle Be sure all tools and personnel are clear before lowering load. Raise load high enough to clear the jack stands. (refer 'Raising the vehicle') Remove jack stands carefully (always used in pairs). Slowly turn the handle counter-clockwise, but no more than 1/2 full turn.
- Page 6 Product Code: 2806T Adding oil With saddle fully lowered set jack in its upright, level position. Remove oil filler plug. Proper oil level will vary from just covering the inner cylinder to 6mm above the inner cylinder as seen from the oil filler plug hole. Reinstall the oil filler plug.
-
Page 7: Troubleshooting
Product Code: 2806T 6. SERVICE & REPAIR Any jack found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge. -
Page 8: Parts List - Main Body Assembly
Product Code: 2806T PARTS LIST - MAIN BODY ASSEMBLY Made in China to TQB Brands Pty Ltd specifications Page 8 Visit us at www.tqbbrands.com.au... - Page 9 Product Code: 2806T Part # Description Part # Description Front Wheel Handle Socket Washer Shaft Retainer Roll Wheel Rear Wheel Assembly Retainer Bearing Bottom Bolt Steel Ball Lower Handle Bearing Cap Hex Cap Bolt Washer Upper Handle Handle Grip Arm Shaft...
-
Page 10: Parts List - Power Unit
Product Code: 2806T PARTS LIST - POWER UNIT Made in China to TQB Brands Pty Ltd specifications Page 10 Visit us at www.tqbbrands.com.au... - Page 11 Product Code: 2806T Part # Description Part # Description 32-1 Tank Nut 32-22 Screw 32-2 O-Ring 32-23 Copper Washer 32-3 Seal Ring 32-24 Pump Base 32-4 Oil Tank 32-25 O-Ring 32-5 Oil Fill Plug 32-26 Snap Ring 32-6 Seal Ring...
-
Page 12: Warranty
Product Code: 2806T WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
