Product Code: 2015
OWNER'S MANUAL
PRODUCT CODE: 2015
12,000kg HYDRAULIC BOTTLE JACK
Lifting
Max. Lifting
Min. Lifting
Hydraulic
Screw
Base
Capacity
Height
Height
Lift
Adjustment
Area
12,000kg
350mm
180mm
100mm
70mm
157 x 134mm
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Advertisement
Table of Contents
Related Manuals for TradeQuip 2015
Summary of Contents for TradeQuip 2015
- Page 1 Product Code: 2015 OWNER’S MANUAL PRODUCT CODE: 2015 12,000kg HYDRAULIC BOTTLE JACK Lifting Max. Lifting Min. Lifting Hydraulic Screw Base Capacity Height Height Lift Adjustment Area 12,000kg 350mm 180mm 100mm 70mm 157 x 134mm Made in China to TQB Brands Pty Ltd specifications Visit us at www.tqbbrands.com.au...
-
Page 2: Table Of Contents
Product Code: 2015 WARNING INFORMATION IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the Tradequip policy of continuous improvement determines the right to make modifications without prior warning. CONTENT WARNING INFORMATION ......................2... -
Page 3: Safety Instructions
Ensure that each stand is securely located under a strong point on the vehicle - ü consult vehicles owner's manual for guidance. Centre the load prior to lifting. ü For your safety, do not modify or alter this Bottle Jack. ü When servicing, use only Tradequip identical replacement parts. Use of any other ü parts will void the warranty. Use the right product for the job. There are certain applications for which the Bottle ü Jack was designed. Do not modify the Bottle Jack and do not use the Bottle Jack for a purpose for which it was not intended. Made in China to TQB Brands Pty Ltd specifications Page 3 Visit us at www.tqbbrands.com.au... -
Page 4: Assembly, Operation & Preventative Maintenance
Product Code: 2015 ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE 1. FEATURES The Tradequip Hydraulic Bottle Jack is designed specifically for lifting and lowering, but not sustaining load. This unit provides enough lifting power for use with most automotive and farm vehicles, heavy duty machinery, industrial construction equipment and more. It’s low profile design get’s you out of tight situations with ease. 2. BEFORE USE Conduct a thorough visual inspection checking for any abnormal conditions, such as cracked welds, and damaged, loose, or missing parts. Bleed any trapped air from the... - Page 5 Product Code: 2015 3. OPERATION Prior to each use always conduct a visual inspection checking for and any abnormal conditions, such as cracked welds, and damaged, loose, or missing parts. The Jack operates when the release valve is closed, an upward stroke of the jack handle draws hydraulic oil from the reservoir tank into the plunger cavity. A downward stroke of the jack handle releases hydraulic oil into the cylinder, which forces the ram up. This raises the saddle. When the ram reaches its maximum extension, oil is bypassed back into the reservoir to prevent over extended ram and possible damage to the jack. Opeing the release valve allows oil to flow back into the reservoir. This releases hydraulic oil pressure on the ram, which results in the lowering of the saddle. To Lift the Vehicle: Block the vehicle's wheels for lifting stability. Secure the load to prevent inadvertent...
- Page 6 Product Code: 2015 4. MAINTENANCE If you use and maintain your equipment properly, it will give you many years of service. Follow the maintenance instructions carefully to keep your equipment in good working condition. Never perform any maintenance on the equipment while it is under a load. Oil Level: The level of oil should be maintained a maximum of 6mm below filler cap. Top up with quality hydraulic ISO VG32 oil. DO NOT use brake/trans fluid or engine oil. Regularly drop oil into the air supply inlet prior to use. Inspection: Inspect the product for damage, wear, broken or missing parts (e.g: pins) and that all components function before each use. Follow lubrication and storage instructions for optimum product performance. Binding: If the product binds while under a load, use equipment with equal or larger load capacity to lower the load safely to the ground. After un-binding clean, lubricate and test that equipment is working properly. Rusty components, dirt, or worn parts can be causes of binding. Clean and lubricate the equipment as indicated in the lubrication section.
- Page 7 Product Code: 2015 5. SERVICE & REPAIR Any Bottle Jack found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge. Only authorised parts, labels, decals shall be used on this equipment. Annual inspection of the Bottle Jacks is recommended and can be made by...
-
Page 8: Parts List
Product Code: 2015 PARTS LIST Part # Description QTY Part # Description QTY Adjustable Saddle Ball 6mm Saddle Socket Ball Stopper Piston Rod Base Nut Bolt O-Ring (Nut) Washer (Pump) Seal Pump Piston O-Ring (Plunger) Bowl Washer Back Ring O-Ring (Piston) Plunger Cylinder R-Pin Reservoir Pin Reservoir Seal Short Pin Base Plate Washer Link Plate Filter Screen Handle Socket Oil Filler Plug Handle Top Release Valve Handle Bottom... -
Page 9: Troubleshooting
Product Code: 2015 TROUBLESHOOTING Problem Cause Solution Release valve not tightly closed Ensure release valve tightly closed Jack will not lift Overload condition Remedy overload condition Air in hydraulic system Purge air from system Release valve not tightly closed Ensure release valve tightly closed Jack bleeds off after lift Overload condition Remedy overload condition Hydraulic unit malfunction Contact place of purchase Jack will not lower after Reservoir overfilled Drain fluid to proper level unloading Linkages binding Clean and lubricate moving parts Fluid level low Drain fluid to fluid level Air trapped in system With ram fully retracted, remove oil Poor lift performance filler plug to let pressurised air escape reinstall oil filler plug Will not lift to full extension Fluid level low Ensure proper fluid level Made in China to TQB Brands Pty Ltd specifications Page 9 Visit us at www.tqbbrands.com.au... -
Page 10: Warranty
Product Code: 2015 WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
