TradeQuip 2826T Owner's Manual

10,000kg air/hydraulic long chassis service jack
Hide thumbs

Advertisement

Quick Links

Download this manual
Jul-18
Product Code: 2826T
OWNER'S MANUAL
PRODUCT CODE: 2826T
10,000kg AIR/HYDRAULIC
LONG CHASSIS SERVICE JACK
Lifting
Lifting
Max
Min
Operating
Nett
Package Size
Capacity
Height
Height
Height
Air Pressure
Weight
10,000kg
400mm
560mm
160mm
0.7-1.0mpa
139kg
1670x520x330mm
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2826T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TradeQuip 2826T

Summary of Contents for TradeQuip 2826T

  • Page 1 Jul-18 Product Code: 2826T OWNER’S MANUAL PRODUCT CODE: 2826T 10,000kg AIR/HYDRAULIC LONG CHASSIS SERVICE JACK Lifting Lifting Operating Nett Package Size Capacity Height Height Height Air Pressure Weight 10,000kg 400mm 560mm 160mm 0.7-1.0mpa 139kg 1670x520x330mm Made in China to TQB Brands Pty Ltd specifications...

  • Page 2: Table Of Contents

    Jul-18 Product Code: 2826T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.

  • Page 3: Safety Instructions

    Jul-18 Product Code: 2826T SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY • Support load by appropriate means after • Only lift areas of the vehicle designated by lifting the vehicle manufacturer.

  • Page 4: Assembly, Operation, Preventitive Maintenance

    ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The TradeQuip Air/Hydraulic Long Chassis Garage Jack features a 'quick lift' foot pedal mechanism with a handle locking facility that allows the handle to be locked in three different height positions. Fitted with rear swivelling castor wheels and large saddle to aid positioning under the vehicle, the jack incorporates safety overload and bypass valves to prevent overloading.
  • Page 5 Jul-18 Product Code: 2826T 3. BEFORE USE Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts. • Consult the vehicle owner’s manual to determine the location of lift points.
  • Page 6 (refer to maintenance section). 6. STORAGE This TradeQuip Air/Hydraulic Long Chassis Garage Jack should always be stored in a dry location on a level surface with the lift arm in the fully lowered position. 7. MAINTENANCE Monthly maintenance is recommended.
  • Page 7 Jul-18 Product Code: 2826T Made in China to TQB Brands Pty Ltd specifications Page 7 Visit us at www.tqbbrands.com.au...
  • Page 8 Add multi-purpose grease to upper arm grease nipple every 3 months. 8. SERVICE & REPAIR Any TradeQuip Air/Hydraulic Long Chassis Garage Jack found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent.

  • Page 9: Troubleshooting

    Jul-18 Product Code: 2826T TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Jack will not lift to • • Release valve is open Close release valve knob full height • • Low/no oil in reservoir Add hydraulic oil to reservoir • • Air-locked system...

  • Page 10: Parts List

    Jul-18 Product Code: 2826T PARTS LIST Part # Description Part # Description Frame 2-15 Screw Front Wheel 2-16 Sealing Washer Washer 2-17 Bolt M12x20 Snap Ring 2-18 Steel Ball Grease Fitting 2-19 Copper Washer Rod Link 2-20 Bolt Bolt 2-21...
  • Page 11 Jul-18 Product Code: 2826T Part # Description Part # Description Washer 4-20 O-Ring Copper Washer 4-21 Piston Body A 4-22 Bolt Bolt 4-23 Air Seal 4-10 Front Cover 4-24 O-Ring 4-11 Steel Ball 4-25 O-Ring 4-12 Air Pump Housing 4-26...
  • Page 12 Jul-18 Product Code: 2826T Made in China to TQB Brands Pty Ltd specifications Page 12 Visit us at www.tqbbrands.com.au...

  • Page 13: Warranty

    Product Code: 2826T WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
