- Page 1 Mar-18 Product Code: 2828 OWNER’S MANUAL PRODUCT CODE: 2828 GARAGE JACK ALUMINIUM Working Load Min.Height Max. Height Net Weight Gross Package Size Limit (kg) (mm) (mm) (kg) Weight (kg) (cm) 2700 25.5 730 x 332 x 175...
-
Page 2: Warning Information
Keep this manual in a convenient and safe place for future reference. Whilst every effort has been made to ensure accuracy of information contained in this manual, the TradeQuip policy of continuous improvement determines the right to make modifications without prior warning. -
Page 3: Table Of Contents
Product Code: 2828 CONTENT WARNING INFORMATION ......................2 CONTENT ............................3 SAFETY INSTRUCTIONS .........................4 ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE ............5 TROUBLESHOOTING ........................8 PARTS LIST ............................9 PARTS LIST DIAGRAM .........................10 PARTS LIST ..........................11 WARRANTY ..........................13 Page 3... -
Page 4: Safety Instructions
Product Code: 2828 SAFETY INSTRUCTIONS WARNING FAILURE TO READ THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE & PERSONAL INJURY Support load by approved jack stands Only lift areas of the vehicle designated by after lifting the vehicle manufacturer. -
Page 5: Assembly, Operation & Preventative Maintenance
Product Code: 2828 ASSEMBLY, OPERATION & PREVENTATIVE MAINTENANCE 1. FEATURES The TradeQuip 2,700kg Super Lightweight Low Profile High Lift Garage Jack is designed for the professional automotive service technician and automotive enthusiasts needing fast acting performance. The long reach, ultra-light weight aluminium and steel combination offers maxi- mum versatility. - Page 6 Product Code: 2828 3.2. Lowering Vehicle Be sure all tools and personnel are clear before lowering load. Raise load high enough to clear the jack stands. (refer 'Raising the vehicle') Remove jack stands carefully (always used in pairs) ...
- Page 7 Product Code: 2828 NOTICE: If the oil level is too low, the jack will not raise to its advertised maximum height. DO NOT overfill the reservoir. An overfilled reservoir can cause a wide variety of performance problems and create an oily mess on the workshop floor! See the troubleshooting guide below.
-
Page 8: Troubleshooting
Product Code: 2828 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Low oil level Check oil level Jack will not lift to full height Release valve not tightly Ensure release valve is Jack will lift, but not maintain pressure closed tightly closed. -
Page 9: Parts List
Product Code: 2828 PARTS LIST Item Description Item Description Bushing, Rear Wheel Long Connecting Rod Bolt, Rear Wheel Pin Roll Universal Wheel Rack Screw Rear Wheel Seat Snap Ring Lock Nut Long Connecting Rod Bushing Lock Nut Connecting Rod, Saddle... -
Page 10: Parts List Diagram
Product Code: 2828 PARTS LIST DIAGRAM Page 10... -
Page 11: Parts List
Product Code: 2828 PARTS LIST Item Description Item Description 54-1 54-25 Compress Spring Plate 54-2 Connect Head 54-26 Steel Retain Ring 54-3 Bolt 54-27 Copper Washer 54-4 Top Nut 54-28 Pump Body 54-5 O-Ring 54-29 O-Ring 54-6 Seal Ring 54-30... - Page 12 Product Code: 2828 Page 12...
-
Page 13: Warranty
Product Code: 2828 WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
