4.3

Removing the head array

This is how you remove the Total Control Head Array from your
wheelchair:
• Turn screws counter-clockwise to loosen them.
• Disconnect cables .
• Press buttons to unlock the swing-away arms and move them outward
from the user.
• Turn lever counter-clockwise and lift the whole head array from the
wheelchair's backrest.
To re-attach the head array, assemble in the reverse order. Make sure that
cables , screws , and lever are all properly fitted and tightened.
Usage - 17
