- Page 1 Isotemp Standard Incubators 600 Series Operation Manual and Parts List LT2068X1 Rev. 2 (7006841) © 2010 Fisher Scientific Inc. All rights reserved Printed in U.S.A.
- Page 2 MANUAL NUMBER LT2068X1 (7006841) 26697/SI-10360 11/23/10 Added Electrical Requirements note - includes 5 amp outlet (pg 2-1) SI-10360 6/29/10 Corrected model numbers above 4/27/10 Transfer to Marietta (was LT2068X1 3/9/09) ECR/ECN DATE DESCRIPTION Fisher Scientific Fisher Scientific Isotemp Standard Incubators...
- Page 3 Fisher Scientific makes no representations or warranties with respect to this manual. In no event shall Fisher Scientific be held liable for any damages, direct or incidental, arising out of or related to the use of this manual.
- Page 4 This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Fisher Scientific has contracted with one or more recycling/disposal companies in each EU Member State European Country, and this product should be disposed of or recycled through them.
- Page 5 When more extensive service is necessary, we will assist you with direct factory trained technicians or a qualified service organization for on-the-spot repair. If your service need is covered by the Fisher Scientific Products warranty, we will arrange for the unit to be repaired at our expense and to your satisfaction.
-
Page 6: Table Of Contents
Schematic ...........9-1 Fisher Scientific... -
Page 8: Introduction
Introduction Section 1 Fisher Isotemp 600 Series Standard incubators are available in three sizes: Small, Medium and Large. All incubators provide PID microprocessor control at operating temperatures ranging from 30 (86°F) to 75°C (167°F). Note Ambient temperature must be at least 5°C below operating temperatures. -
Page 10: Specifications
11-690-637D ..120V, 60 Hz, 7.2A, 864W 11-690-638D ..240V, 50/60 Hz, 6.1A, 1464W Large incubators 11-690-650D ..120V, 60 Hz, 7.7A, 924W 11-690-651D ..240V, 50/60 Hz, 6.4A, 1536W Fisher Scientific Isotemp Standard Incubators... - Page 11 Operating: 17°C to 27°C; 20% to 80% RH, non-condensing. Installation Category II (overvoltage) in accordance with IEC 664. Pollution Degree 2 in accordance wth IEC 664. Altitude Limit: 2,000 meters. Storage: -25°C to 65°C, 10% to 85% relative humidity (RH) Isotemp Standard Incubators Fisher Scientific...
-
Page 12: Installation
Fisher Scientific Isotemp® Incubators are shipped in a single carton. After unpacking, locate each item shown in the list below. Report any missing items, by name and part number, to your Fisher Scientific distributor. In the event of shipping damage, retain the carton and packing material and file a claim with the final carrier. -
Page 13: Convenience Outlet
5A for all incubators. If the current limit is exceeded, the circuit breaker will trip. For safety, the integrity of the electrical ground should always be maintained. Isotemp Standard Incubators Fisher Scientific... -
Page 14: Controls
Alarm Indicator Lights if the actual incubator temperature exceeds the alarm temperature. The alarm temperature is factory-adjusted to be 5°C above the set temperature. Program Indicator Lights when the control temperature is being set. Fisher Scientific Isotemp Standard Incubators... -
Page 15: Keypad
Pressing the SET Key causes the display to show the set temperature. Used with INCREASE Key and DECREASE Key to change the set temperature. With MENU Key to access entry of a temperature display offset (calibration feature). Isotemp Standard Incubators Fisher Scientific... -
Page 16: Operation
Note Upon initial heat up to temperature, the over range alarm indicator light may illuminate briefly (several minutes) until the temperature stabilizes at the set point. The incubator temperature should be allowed to stabilize prior to loading samples. Fisher Scientific Isotemp Standard Incubators... -
Page 17: Alarm Limits
40 and the unit went into alarm. The researcher, knowing this was a normal operation, allowed the unit to cool and stabilize at 40°C. Just below 43°, the unit alarm LED went off and the display resumed normal operation. Isotemp Standard Incubators Fisher Scientific... -
Page 18: Display Offsets
The displayed temperature is the result of algebraically adding the actual temperature to the offset value. Thus, if an offset value of –3° is being used, a measured temperature of 50° will be displayed as 47°. Fisher Scientific Isotemp Standard Incubators... -
Page 20: Service
2. During cleaning, take precautions to prevent cleaning agents from contacting electrical components. 3. Use a mild, non-abrasive cleaner (i.e. damp cloth and mild soap) to clean all normally accessible surfaces. 4. Make sure unit is dry before re-connecting to power source. Fisher Scientific Isotemp Standard Incubators... -
Page 21: Replacing The Door Gasket
Section 6 Service Replacing the Door Isotemp 600 Series incubators incorporate a durable, silicone door gasket to minimize heat loss. Should the gasket become defective or be damaged, Gasket it may be replaced by following the procedure below. Note Study the method of door gasket attachment before starting disassembly. -
Page 22: Replacing The Heater
6. Install replacement heater and reassemble unit by generally reversing the steps above. Bezel Screws Controller and relays inside bezel Heater Cover Screws Figure 6-1. Locations Heater Cover Fisher Scientific Isotemp Standard Incubators... -
Page 23: Replacing The Solid State Relay
8. Lift out the solid state relay. Put new solid state relay in place, making certain that the thin, conductive pad remains between the solid state relay and the bezel. 9. Generally reverse the steps above to reassemble incubator. Isotemp Standard Incubators Fisher Scientific... -
Page 24: Replacing The Control Thermocouple
Remove thermocouple from clip. 8. Pull thermocouple forward into chamber, exposing roughly a 6 inch section of the thermocouple wire. 9. Cut the thermocouple wire to remove the thermocouple sheath. Fisher Scientific Isotemp Standard Incubators... -
Page 25: Replacing The Door Handle
For thermocouples, the red wire is negative and yellow positive. Replacing the Glass The Isotemp 600 series incubators feature a glass, inner door to allow the Door chamber to be viewed with minimal heat loss. Should the glass door become damaged, it may be replaced by following the procedures below. -
Page 26: Adjusting The Door Cam
5. Secure cam tongue in place by tightening outside nut. 6. Repeat Steps 1 thru 5 as necessary to get desired door seal. 7. Secure latch cover in place with two screws. Fisher Scientific Isotemp Standard Incubators... -
Page 28: Troubleshooting
Alarm LED stays on and control is higher than set Defective controller Replace controller temperature Defective solid state relay or safety Refer to schematic and replace relay relay. Fisher Scientific Isotemp Standard Incubators... - Page 29 Set Display Shows “EEE” broken connections rear of temperature controller. Defective control Replace control if thermocouple is OK. Begin by setting offset to 0. Temperature off from Calibration offset needs Independent thermometer adjusted. (See Display Offsets.) Isotemp Standard Incubators Fisher Scientific...
-
Page 30: Replacement Parts
Solid State Relay 88616 Safety Relay 120V units SPN 95770 240V units SPN 95787 Circuit Breaker Single Pole (120V) SPN 95764 Double Pole (240V) SPN 95766 Door Assembly Small units DR2034X8 Medium units DR2033X8 Large units DR2032X8 Fisher Scientific Isotemp Standard Incubators... - Page 31 Solid State Relay 88616 Safety Relay 120V units SPN 95770 240V units SPN 95787 Circuit Breaker Single Pole (120V) SPN 95764 Double Pole (240V) SPN 95766 Door Assembly Small units DR2034X6 Medium units DR2033X6 Large units DR2032X6 Isotemp Standard Incubators Fisher Scientific...
-
Page 32: Schematic
Section 10 Section 10 Section 10 Schematic Schematic Schematic Fisher Scientific Isotemp Standard Incubators... - Page 34 For customer service, call 1-800-766-7000 To fax an order, use 1-800-926-1166 To order online: www.fishersci.com...
