Chapter 2: Jumpers and Connectors
COM1 Port Power Setting
Connector type: 2x3 6-pin header
Connector location: JCOM1_RI1
2
6
1
5
Pin
Settings
1-2 On
+12V
3-4 On
RING
5-6 On
+5V
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
COM2 Port Power Setting
Connector type: 2x3 6-pin header
Connector location: JCOM2_RI1
2
6
1
5
Pin
Settings
1-2 On
+12V
3-4 On
RING
5-6 On
+5V
12
NISE 4300 User Manual
