FM2 Quick Start Guide
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FM2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teltonika FM2

Summary of Contents for Teltonika FM2

  • Page 1 FM2 Quick Start Guide V1.0...

  • Page 2: Table Of Contents

    ELEMENTS FM2 DEBUG MODE .............................9 COMPATIBILITY...............................10 Copyright © Teltonika 2008 All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Teltonika is prohibited.

  • Page 3: Physical Connection

    1. Physical connection 1.1 SIM card insert scheme Figure 1. SIM card insert scheme Open the SIM holder and insert the SIM card as shown. Close the SIM holder Push SIM holder’s top part in shown direction to clip SIM holder Assemble device with enclosure’s top part as shown and screw the bolts.

  • Page 4: Power Supply Connection

    Do not plug it to PC’s USB port. Please use cables provided with FM2100 device. 2. Configuration 2.1 First steps Launch FM2 configurator, choose COM port to which FM2 is connected and click 'Connect'. Click 'Load Default Profile' – this will load a template for all settings.

  • Page 5: System Settings

    All these settings are active and FM2 is using them all to record new coordinates. By default time interval should be used to set interval for object when it is not moving, distance should be used to determine maximum distance between points when vehicle is moving in a straight line and angle should serve as precision corrector.

  • Page 6: Gsm Settings

    'GSM Settings' allows to set protocol used for data transfers – TCP or UDP. 'Min Saved Records' defines minimum number of coordinates that should be transferred with one connection to server. If FM2 does not have enough coordinates to send to server, it will check again after time interval defined in 'Sending Period' (see below).

  • Page 7: Gprs Settings

    Essential fields in 'SMS Settings' are 'Login' and 'Password'. This login and password should be used with every SMS sent to FM2 as identifiers and means of protection from SMS from unauthorised numbers. More information about SMS sending can be found in 'FM2 SMS Command List' document.
  • Page 8 'SMS Data Send' field defines if FM2 is able to send periodic data and high priority event SMS to the server. Note, that it does not prevent FM2 from sending back replies to configuration commands or requests. Periodic data messages are sent in binary format to number specified in 'Server Phone Number' field.

  • Page 9: Send Parameters

    'Send Week Time' table indicates when new GPRS connection can be opened. FM2 algorithm allows to open new GPRS session if current time is less than 10 minutes before nearest checked timestamp, therefore if all table is checked, FM2 is always allowed to open new GPRS session.

  • Page 10: Fm2 Debug Mode

    'SMS settings' is enabled – see above). 3. FM2 debug mode FM2 is able to transmit its current state when connected to PC using PORT1 cable. It is used to detect errors and provide information to possible solutions when operating as unexpected.

  • Page 11: Compatibility

    4. Compatibility FM2 uses FM4 data protocol as well as configuration protocol. Some property IDs have changed – new properties are listed in FM2 parameter and functionality description.
