- Page 1 Owner’s Manual 10' Offset Umbrella with Base Model Number: UMB-10-STD SKU Number: 101644194 Additional Product Information: https://shadenshelters.com/10-round-offset-umbrella 1 of 9...
-
Page 2: Parts List
Parts List 10' Offset Umbrella with Base Letter Illustration Description Qty. Letter Illustration Description Qty. Poly Base - Base Plate Middle Main Support Post with Base Plate Umbrella Canopy Swivel Plate M8 x 15mm Bolt Lower Umbrella M8 x 20mm Bolt Support Post Swivel Plate Steel Washer... - Page 3 Assembly Instructions 10' Offset Umbrella with Base Important: ⚫ Read all the instructions before assembly. Failure to do so may result in faulty assembly and potential injury. Before beginning to assemble the product, remove all protective materials, hardware kit(s), and ⚫...
- Page 4 Step 2: Remove caps from the side of all Poly Bases (G & H) and fill completely with Sand or Water. Secure the caps on all bases. See Figure 2. Note: Poly Bases must be completely filled with sand or water before proceeding to the next step. Figure 2 Step 3: Place the Filled Poly Bases (G &...
- Page 5 Step 4: Remove the Locking Nuts from the Lower Umbrella Support Post (D) and attach the Bottom Swivel Plate Cover (E) and Top Swivel Plate Cover (F). See Figure 4. Note: The Locking Nut is reattached in Step 5. Locking Nuts Figure 4 Step 5: Insert the Main Support Post with Umbrella Canopy (I) into the Lower Umbrella Support Post (D).
- Page 6 OPERATING INSTRUCTIONS Step 6: RAISING UMBRELLA CANOPY. Untie the Tie Strap and loosen the Umbrella Fabric before raising. See Figure 6. Note: The Umbrella Canopy must be in the closed position prior to raising or lowering the height. Figure 6 Step 7: Slowly lift the curved bar upwards to extend the canopy to the highest position.
- Page 7 Step 8: OPENING UMBRELLA CANOPY. Once the Umbrella Canopy is at the desired height, open the Canopy by turning the Umbrella Crank in the clockwise position. To close the Umbrella Canopy, turn the Umbrella Crank in the counter clockwise position. See Figure 8. Figure 8 Step 9: ROTATING UMBRELLA CANOPY.
- Page 8 Step 10: LOWERING UMBRELLA CANOPY. Close the Umbrella Canopy by turning the Umbrella Crank counter-clockwise. See Figure 10-1. Release the Arm Lock by moving the Sleeve in the upward direction. Release the Height Lock by raising the lever to the unlock position. Slowly lower the curved bar to the lowest position. See Figure 10-2.
-
Page 9: Care And Maintenance
Care & Maintenance Maintain your umbrella by storing out of the elements when not in use. Frame: Clean frames with a mild soap and warm water. Do not use abrasive materials, cleaners or bleach. Rinse with clean water and dry thoroughly. Always clean, drain and dry thoroughly before storing for the winter.
