Second Edition • Third Printing
GS-3369RT
Height, working maximum
Height, platform maximum
Height, stowed maximum,
rails up
Height, stowed maximum,
rails lowered
Height, guard rails
Width
Length, platform retracted
Length, platform retracted,
models with outriggers
Length, platform extended
Length, platform extended,
models with outriggers
Length, outside platform
extended
Maximum load capacity
Maximum wind speed
Wheelbase
Turning radius (outside)
Turning radius (inside)
Ground clearance
Weight
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Controls
AC outlet in platform
Platform dimensions
Platform length x width
Platform extension
length
Part No. 1298222GT
39 ft
11.9 m
32.67 ft
10 m
102 in
2.59 m
75.5 in
192 m
58 in
1.47 m
69 in
1.75 m
123 in
3.12 m
148 in
3.76 m
177.5 in
4.51 m
189.5 in
4.81 m
170 in
4.32 m
1000 lbs
454 kg
28 mph
12.5 m/s
90 in
2.29 m
181.2 in
4.6 m
83 in
2.11 m
9½ in
24 cm
7695 lbs
3490 kg
Proportional
Standard
110 in x 63 in
2.79 x 1.6 m
105 in
2.67 m
GS™-2669RT • GS™-3369RT • GS™-4069RT
Drive speeds
Stowed, maximum
3.5 mph
Platform raised,
0.3 mph
maximum
Maximum hydraulic
3500 psi
pressure (functions)
Tire size
Ambient operating
temperature
Maximum slope rating, stowed
position
Maximum side slope rating,
stowed position
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Maximum allowable chassis
inclination
Floor loading information
Tire load maximum
Outrigger load, maximum
Tire contact pressure
Outrigger contact pressure
Occupied floor pressure
Note: Floor loading information is approximate and
does not incorporate different option configurations. It
should be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
Operator's Manual
Specifications
5.63 km/h
0.48 km/h
40 ft/90
12.2 m/90 sec
sec
241 bar
26x12D380
-20° F to 120° F
-29° C to 49° C
35% (19°)
35% (19°)
Refer to "Tilt Sensor
Activation Settings"
section
3058
1387 kg
lbs
3058
1387 kg
lbs
76.1 psi
5.35 kg/cm
524 kPa
38.9 psi
2.74 kg/cm
268 kPa
172 psf
838 kg/m
8.22 kPa
2
2
2
55
