Operator's Manual
Operating Instructions
Operation from Ground
1 Turn the key switch to ground control.
2 Pull out both ground and platform red
Emergency Stop buttons to the on position.
3 Start the engine.
To Position Platform
1 Push and hold the lift function
enable button.
2 Activate the up function or the
down function.
Drive and steer functions are not available from
the ground controls.
Engine Idle Select
Select the engine idle (rpm) by pressing the idle
select button. There are two settings for engine
idle:
Indicator light off: low idle
•
Indicator light on: high idle
•
42 GS™-2669RT • GS™-3369RT • GS™-4069RT
Second Edition • Third Printing
Operation from Platform
1 Turn the key switch to platform control.
2 Pull out both ground and platform red
Emergency Stop buttons to the on position.
3 Start the engine.
To Position Platform
1 Push and hold the lift function
enable button.
2 Activate the up/down rocker switch
in the desired direction.
To Steer
1 Press and hold the function enable switch on
the control handle.
2 Turn the steer wheels with the thumb rocker
switch located on the top of the control handle.
Part No. 1298222GT
