Terex Genie GS-2669RT Operator's Manual
  1. Manuals
  2. Brands
  3. Terex Manuals
  4. Scissor Lifts
  5. Genie GS-2669RT
  6. Operator's manual

Terex Genie GS-2669RT Operator's Manual

Hide thumbs Also See for Genie GS-2669RT:
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's Manual
GS
-2669RT
™
GS
-3369RT
™
GS
-4069RT
™
Serial Number Range
from GS69F-18000
CE
with
Maintenance
Information
Original Instructions
Third Edition
First Printing
Part No. 1305657GT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genie GS-2669RT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Terex Genie GS-2669RT

Summary of Contents for Terex Genie GS-2669RT

  • Page 1 Operator's Manual Serial Number Range -2669RT ™ from GS69F-18000 -3369RT ™ -4069RT ™ with Maintenance Information Original Instructions Third Edition First Printing Part No. 1305657GT...

  • Page 2: Table Of Contents

    Specifications ............50 Copyright © 2011 by Terex Corporation Third Edition: First Printing, August 2020 Genie is a registered trademark of Terex South Dakota, Inc. in the U.S.A. and many other countries. “GS” is a trademark of Terex South Dakota, Inc.

  • Page 3: Introduction

    Third Edition • First Printing Operator's Manual Introduction Introduction About this manual Intended Use and Familiarization Guide Genie appreciates your choice of our machine for your application. Our number one priority is user The intended use of this machine is to lift personnel, safety, which is best achieved by our joint efforts.
  • Page 4 Third Edition • First Printing Operator's Manual Introduction Platform contols symbology and releated Ground controls symbology and related machine movement: machine movement: Lift function enable button Lift function enable button Platform up/down button Outrigger auto level button (when thumb rocker switch moved up or down) Sequential functions and movement: Platform up/down (when lift...
  • Page 5 Third Edition • First Printing Operator's Manual Introduction Bulletin Distribution and Compliance Contacting the Manufacturer Safety of product users is of paramount importance At times it may be necessary to contact Genie. to Genie. Various bulletins are used by Genie to When you do, be ready to supply the model number communicate important safety and product and serial number of your machine, along with your...
  • Page 6 Third Edition • First Printing Operator's Manual Introduction Safety Sign Maintenance Replace any missing or damaged safety signs. Keep operator safety in mind at all times. Use mild soap and water to clean safety signs. Do not use solvent-based cleaners because they may damage the safety sign material.

  • Page 7: Symbol And Hazard Pictorials Definitions

    Third Edition • First Printing Operator's Manual Symbol and Hazard Pictorials Definitions Symbol and Hazard Pictorials Definitions Read the operator’s Read the service Crush hazard Crush hazard Collision hazard manual manual Tip-over hazard Tip-over hazard Tip-over hazard Tip-over hazard Electrocution hazard Electrocution hazard Explosion hazard Fire hazard...
  • Page 8 Third Edition • First Printing Operator's Manual Symbol and Hazard Pictorials Definitions Lower the platform. Do not set up where it Maintain required Access by trained and Use a piece of cannot be leveled with authorized personnel cardboard or paper clearance outriggers only...
  • Page 9 Third Edition • First Printing Operator's Manual Symbol and Hazard Pictorials Definitions Voltage rating for Pressure rating for air Maximum capacity Fall hazard 100% Restraint power to platform line to platform Burn hazard stay Transport diagram Collision hazard Lanyard anchorage away points Platform overloaded...

  • Page 10: General Safety

    Third Edition • First Printing Operator's Manual General Safety General Safety ™ -2669RT • GS ™ -3369RT • GS ™ -4069RT Part No. 1305657GT...
  • Page 11 Third Edition • First Printing Operator's Manual General Safety ™ -2669RT • GS ™ -3369RT • GS ™ Part No. 1305657GT -4069RT...
  • Page 12 Third Edition • First Printing Operator's Manual General Safety ™ -2669RT • GS ™ -3369RT • GS ™ -4069RT Part No. 1305657GT...

  • Page 13: Personal Safety

    Third Edition • First Printing Operator's Manual Personal Safety Personal Safety Personal Fall Protection Personal fall protection equipment (PFPE) is not required when operating this machine provided the operator remains inside the perimeter of the platform guardrail system. If PFPE is required by job site or employer rules, the following shall apply: All PFPE must comply with applicable governmental regulations and must be inspected...

  • Page 14: Work Area Safety

    Third Edition • First Printing Operator's Manual Work Area Safety Work Area Safety Tip-over Hazards Electrocution Hazards Occupants, equipment and materials shall not This machine is not electrically insulated and will exceed the maximum platform capacity or the not provide protection from contact with or proximity maximum platform capacity of the platform to electrical current.
  • Page 15 Third Edition • First Printing Operator's Manual Work Area Safety Do not raise the platform Do not raise the platform when wind speeds may unless the machine is on a exceed 28 mph / 12.5 m/s. If wind speeds exceed firm, level surface.
  • Page 16 Third Edition • First Printing Operator's Manual Work Area Safety Do not drive the machine on or near uneven terrain, Do not modify or alter a mobile elevating work unstable surfaces or other hazardous conditions platform without prior written permission from the with the platform raised.
  • Page 17 Third Edition • First Printing Operator's Manual Work Area Safety Crushing Hazard Fall Hazards Keep hands and limbs out of scissors. The guard rail system provides fall protection. If occupant(s) of the platform are required to wear Keep hands clear when folding rails. personal fall protection equipment (PFPE) due to job site or employer rules, PFPE and its use shall Do not work under the platform or in the scissor...
  • Page 18 Third Edition • First Printing Operator's Manual Work Area Safety Collision Hazards Do not lower the platform unless the area Be aware of limited sight below is clear of distance and blind spots personnel and when driving or operating. obstructions. Be aware of extended platform position when moving the machine.
  • Page 19 Third Edition • First Printing Operator's Manual Work Area Safety Bodily Injury Hazard Explosion and Fire Hazards Always operate the machine in a well-ventilated Do not start the engine if you smell or detect liquid area to avoid carbon monoxide poisoning. petroleum gas (LPG), gasoline, diesel fuel or other explosive substances.
  • Page 20 Third Edition • First Printing Operator's Manual Work Area Safety Outrigger Safety Battery Safety Tip-over Hazards Burn Hazards Do not lower the outriggers unless the machine is Batteries contain acid. Always on a firm surface. Avoid drop-offs, holes, unstable wear protective clothing and or slippery surfaces and other possible hazardous eye wear when working with conditions.

  • Page 21: Legend

    Third Edition • First Printing Operator's Manual Legend Legend Platform entry gate 10 Ground controls side covers 16 Outrigger footpad (if equipped with outriggers) Platform guard rails 11 Hydraulic tank (behind cover) 17 Steer tire Lanyard anchorage points 12 Tilt alarm (behind cover) 18 Engine side covers Platform extension lock 13 Hydraulic oil level indicator...

  • Page 22: Controls

    Third Edition • First Printing Operator's Manual Controls Controls The ground control station is to be used as a means to raise the platform for function tests and for storage purposes. The ground control station can be used in the event of an emergency to rescue an incapacitated person in the platform.
  • Page 23 Third Edition • First Printing Operator's Manual Controls Ground Control Panel LCD readout screen Hour meter Lift function enable button Press this button to activate the lift function. The hour meter displays the number of hours the machine has operated. Platform up button diagnostic display Press this button and the platform will raise.
  • Page 24 Third Edition • First Printing Operator's Manual Controls Platform Control Panel ™ -2669RT • GS ™ -3369RT • GS ™ -4069RT Part No. 1305657GT...
  • Page 25 Third Edition • First Printing Operator's Manual Controls Platform Control Panel Machine on incline button with indicator light: Low speed operation for inclines Outrigger auto level button Press this button to select low speed operation Press this button to activate the auto level for inclines.
  • Page 26 Third Edition • First Printing Operator's Manual Controls 13 Thumb rocker switch for steer function Press the left side of the thumb rocker and the machine will steer to the left. Press the right side of the thumb rocker and the machine will steer to the right.

  • Page 27: Inspections

    Third Edition • First Printing Operator's Manual Inspections Inspections Pre-operation Inspection Fundamentals It is the responsibility of the operator to perform a pre-operation inspection and routine maintenance. The pre-operation inspection is a visual inspection performed by the operator prior to each work shift. Do Not Operate Unless: The inspection is designed to discover if anything is apparently wrong with a machine before the...
  • Page 28 Third Edition • First Printing Operator's Manual Inspections Pre-operation Inspection  Safety arm  Platform extension  Be sure that the operator’s, safety, and  Scissor pins and retaining fasteners responsibilities manuals are complete, legible and in the storage container located in the ...
  • Page 29 Third Edition • First Printing Operator's Manual Inspections Function Test Fundamentals The function tests are designed to discover any malfunctions before the machine is put into service. The operator must follow the step-by-step instructions to test all machine functions. A malfunctioning machine must never be used. If malfunctions are discovered, the machine must be Do Not Operate Unless: tagged and removed from service.
  • Page 30 Third Edition • First Printing Operator's Manual Inspections At the Ground Controls Test the Up/Down Functions The audible warnings on this machine and the Select a test area that is firm, level and free of standard horn all come from the same central alarm. hazards.
  • Page 31 Third Edition • First Printing Operator's Manual Inspections Test the Tilt Sensor Operation At the Platform Controls Note: Perform this test from the ground with the Test Emergency Stop platform controller. Do not stand in the platform. 17 Push in the platform red Emergency Stop 10 Fully lower the platform.
  • Page 32 Third Edition • First Printing Operator's Manual Inspections Test Up/Down Functions and Function Test the Steering Enable Note: When performing the steer and drive function tests, stand in the platform facing the steer end of 20 Start the engine. the machine. 21 Activate the up/down rocker switch in the 26 Press and hold the function enable switch on direction indicated by the blue arrow.
  • Page 33 Third Edition • First Printing Operator's Manual Inspections Test Drive and Braking Test Limited Drive Speed 29 Press and hold the function enable switch on 33 Press and hold the lift function enable button. the control handle. Raise the platform approximately 7.5 ft / 2.28 m from the ground.
  • Page 34 Third Edition • First Printing Operator's Manual Inspections Test Auxiliary Lowering Test the Outrigger System (if equipped) 36 Push and hold the lift function enable button 40 Push and hold the auto level button. and raise the platform approximately 2 ft / 60 cm.
  • Page 35 Third Edition • First Printing Operator's Manual Inspections Workplace Inspection Fundamentals The workplace inspection helps the operator determine if the workplace is suitable for safe machine operation. It should be performed by the operator prior to moving the machine to the workplace.
  • Page 36 Third Edition • First Printing Operator's Manual Inspections Decals Inspection with Symbols Part No. Decal Description 1294398 Label – ANSI/CSA Compliant Use the pictures on the next page to verify that all 1294688 Label – Platform Overload LED decals are legible and in place. Indicator Light Below is a numerical list with quantities and 1295448 Ground Control Panel...
  • Page 37 Third Edition • First Printing Operator's Manual Inspections ™ -2669RT • GS ™ -3369RT • GS ™ Part No. 1305657GT -4069RT...

  • Page 38: Operating Instructions

    Third Edition • First Printing Operator's Manual Operating Instructions Operating Instructions Fundamentals The Operating Instructions section provides instructions for each aspect of machine operation. It is the operator’s responsibility to follow all the safety rules and instructions in the operator’s, safety, and responsibilities manuals.
  • Page 39 Third Edition • First Printing Operator's Manual Operating Instructions All models Emergency Stop If the engine fails to start after 15 seconds of Push in the red Emergency Stop button to the off cranking, determine the cause and repair any position at the ground controls or the platform malfunction.
  • Page 40 Third Edition • First Printing Operator's Manual Operating Instructions Operation from Ground Operation from Platform Turn the key switch to ground control. Turn the key switch to platform control. Pull out both ground and platform red Pull out both ground and platform red Emergency Stop buttons to the on position.
  • Page 41 Third Edition • First Printing Operator's Manual Operating Instructions To Drive Driving on a slope Press and hold the function enable switch on Determine the slope and side slope ratings for the the control handle. machine and determine the slope grade. Increase speed: Slowly move the control Maximum slope rating, stowed position: handle off center.
  • Page 42 Third Edition • First Printing Operator's Manual Operating Instructions To determine the slope grade: To Extend and Retract Platform Measure the slope with a digital inclinometer OR Lift the platform extension lock handles to the use the following procedure. horizontal position. You will need: Push the platform extension lock handles to extend the platform to the desired position.
  • Page 43 Third Edition • First Printing Operator's Manual Operating Instructions Emergency Lowering Outrigger Operation (if equipped) Position the machine below the desired work At the Ground Controls area. Push and hold the lift function enable Note: The engine must be running for the outriggers button and activate the down function.
  • Page 44 Third Edition • First Printing Operator's Manual Operating Instructions Tilt Sensor Activation Settings Chassis Angle on Wheels Chassis Angle (side to side) 2° Chassis Angle (front to back) 3° Chassis Angle on Outriggers Chassis Angle (side to side) 0.8° Chassis Angle (front to back) 3°...

  • Page 45: Transport And Lifting Instructions

    Third Edition • First Printing Operator's Manual Transport and Lifting Instructions Transport and Lifting Instructions Free-wheel Configuration for Winching Chock the wheels to prevent the machine from rolling. 4WD models: Release the Observe and Obey: wheel brakes by turning over the two rear torque hub ...
  • Page 46 Third Edition • First Printing Operator's Manual Transport and Lifting Instructions Use chains or straps of ample load capacity. Securing to Truck or Trailer for Transit Turn the key switch to the off position and remove the key before transporting. Always chock the machine wheels in preparation for transport.
  • Page 47 Third Edition • First Printing Operator's Manual Transport and Lifting Instructions Center of gravity X Axis Y Axis 42.5 in 30.9 in GS-2669RT without outriggers 108.01 cm 78.5 cm 42.6 in 31.4 in GS-3369RT without outriggers 108.2 cm 79.8 cm 38.8 in 31.1 in GS-4069RT without outriggers...

  • Page 48: Maintenance

    Third Edition • First Printing Operator's Manual Maintenance Maintenance Check the Engine Oil Level Maintaining the proper engine oil level is essential to good engine performance and service life. Operating the machine with an improper oil level Observe and Obey: can damage engine components.
  • Page 49 Third Edition • First Printing Operator's Manual Maintenance Diesel Fuel Requirements Check the Hydraulic Oil Level Satisfactory engine performance is dependent on Maintaining the hydraulic oil at the proper level is the use of a good quality fuel. The use of a good essential to machine operation.
  • Page 50 Third Edition • First Printing Operator's Manual Maintenance Check the Batteries Check the Engine Coolant Level Proper battery condition is essential to good Maintaining the engine coolant at the proper level is machine performance and operational safety. essential to engine service life. Improper coolant level will affect the engine’s cooling capability and Improper fluid levels or damaged cables and connections can result in component damage and...
  • Page 51 Third Edition • First Printing Operator's Manual Maintenance Scheduled Maintenance Maintenance performed quarterly, annually and every two years must be completed by a person trained and qualified to perform maintenance on this machine according to the procedures found in the service manual for this machine. Machines that have been out of service for more than three months must receive the quarterly inspection before they are put back into service.

  • Page 52: Specifications

    Third Edition • First Printing Operator's Manual Specifications Specifications GS-2669RT Airborne noise emissions Height, working maximum 32 ft 9.8 m Sound pressure level at ground <85 dBA workstation Height, platform maximum 26.2 ft 10 m Sound pressure level at platform <79 dBA Height, stowed maximum, 102 in...
  • Page 53 Third Edition • First Printing Operator's Manual Specifications Airborne noise emissions GS-3369RT Sound pressure level at ground <85 dBA Height, working maximum 39 ft 11.9 m workstation Height, platform maximum 32.67 ft 10 m Sound pressure level at platform <79 dBA Height, stowed maximum, 102 in 2.59 m...
  • Page 54 Third Edition • First Printing Operator's Manual Specifications Airborne noise emissions GS-4069RT Sound pressure level at ground <85 dBA Height, working maximum 46 ft 14 m workstation Height, platform maximum 40.25 ft 12.3 m Sound pressure level at platform <78 dBA Height, stowed maximum, 108 in 2.74 m...
  • Page 55 Third Edition • First Printing Operator's Manual Specifications Contents of EC Declaration of Conformity <Manufacturer’s name> hereby declares that the machinery described below complies with the provisions of the following Directives: 1. EC Directive 2006/42/EC, Machinery Directive, under consideration of harmonized European standard EN280 as described in EC type-examination certificate <variable field>...
