Introducing the HP Procurve Switch 2124

Front of the Switch

Front of the Switch
Link and
Mode LEDs
Power
Fault
for each
LED
LED
port

Reset button

LED Mode Select button

Network Ports

I
I
Reset Button
This button is used to reset the switch while it is powered on. This action
executes the switch self test, and may clear certain error conditions that have
occurred.
1-2
Slot for
HP 100-FX SC Transceiver
All 10/100Base-TX RJ-45 ports have the "HP Auto-MDIX" feature
and indicator LEDs
24 auto-sensing 10/100Base-TX RJ-45 ports
All these ports have the "HP Auto-MDIX" feature, which means that you
can use either straight-through or crossover twisted-pair cables to
connect any network devices to the switch.
One transceiver slot for installing the HP 100-FX SC Transceiver
(HP J4853A)
10/100Base-TX RJ-45 ports
