Quadra-Fire QFI35FB-IFT Owner's Manual page 26

#15 Bottom Assembly
15.2
IMPORTANT: THIS IS DATED INFORMATION
Hearth and Home Technologies does not sell directly to consumers
distributor.
model number and serial number when requesting service parts from your dealer or distributor.
ITEM
15.1 IFT Wire Harness
15.2 Wire Assembly
15.3 Fuse Wire Assembly
15.4 UAB-C and Mounting Plate Assembly
15.5 Battery Pack**
15.6 Reset Switch Wire
15.7 Reset Switch
15.8 Cable, B Type AC Module
15.9 Component Tray
15.10 Module, RF FCC
15.11 Module, IFT Control
15.12 Module, B Type AC
15.13 Transformer, 6 Volt Wall
15.14 Power Cord
**Fuse for battery pack can be sourced locally, not a warranty item. Specs are 250v, 3A fuse, 3/4" long
Additional service part numbers on following page.
