Operation

10
5 Operation
This section will describe the normal operation of the Multi Scan NXA83 and the
interactions with the user screens.
The screens shown on the LCD display are highly configurable. Whilst those shown in this
section are only examples of what can be displayed, the basic navigation between screens
will remain the same.
For more information on configuring the displays refer to the Multi Scan NXA83
Configuration manual (BA01291G).
5.1

Starting and Stopping

When power is applied to the Multi Scan NXA83 the Green power LED will be illuminated
and the Windows XPe operating system will start to boot.
This will take around three minutes, during which time a number of windows boot messages
will be displayed before automatically logging into the user account, at which point the
Endress+Hauser wait message will be displayed.
The boot will be complete when the GridView display is shown. At this point the system is
fully operational, with all interfaces active (master and slaves).
It is perfectly safe to switch off the power without shutting down the operating system. The
Multi Scan NXA83 contains an Enhanced Write Filter which protects the system from being
corrupted due to a loss of power (see configuration document for description).
Tankvision
NXA83_E+H_Wait_Message
NXA83_Display_Grid-View
