Startup

After the IP phone is connected to the network and supplied with
power, it automatically begins the initialization process. After
startup, the phone is ready for use. You can configure the phone
via web user interface or phone user interface.
Configuring Your Phone
Configuring via web user interface
Accessing the web user interface:
1. Press the key when the phone is idle to obtain the IP address of the phone.
2. Open a web browser on your computer, enter the IP address into the address bar (e.g., "http://192.168.0.10"
or "192.168.0.10"), and then press the Enter.
3. Enter the user name (default: admin) and password (default: 1234) in the login page and click Confirm.
Network Settings: Click on Network->Basic->IPv4 Config
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP Server in your network to obtain its valid
network settings, e.g., IP Address, Subnet Mask, Gateway Address and DNS Address.
Static IP Address: If the phone cannot contact a DHCP Server for any reason, you need to configure the
IP Address, Subnet Mask, Gateway Address, Primary DNS Address and Secondary DNS Address for the
phone manually.
PPPoE: If you are using an xDSL modem, you can connect your phone to the Internet via PPPoE mode.
Contact the ITSP for the PPPoE User Name and Password.
Note: The IP phone also supports IPv6, but IPv6 is disabled by default.
The wrong network settings may result in inaccessibility of the phone and may have an impact on the
network performance. Contact your system administrator for more information.
Account Settings: Click on Account->Register
Parameters of the account:
Register Status:
Line Active:
Label:
Display Name:
Register Name:
User Name:
Password:
Server Host:
Register status icons on the LCD screen:
Registered
Note: Check with your system administrator if any error appears during the registration process or a specific
configuration is required for your registration.
Configuring via phone user interface
Network Settings:
Press the Menu soft key when the phone is idle, select Settings->Advanced Settings (default password: admin)
->Network-> WAN Port/VLAN/Webserver Type/802.1x Settings/VPN/LLDP/CDP/NAT to configure the network.
3
It shows the register status of the current account.
You can select Enabled/Disabled to enable/disable the account.
It is shown on the LCD screen to identify the account.
It is shown as Caller ID when placing a call.
It is an authenticated ID for authentication provided by ITSP (required).
It is provided by ITSP for registration (required).
It is provided by ITSP for registration (required).
It is provided by ITSP for registration (required).
Initializing...please wait Initializing...please wait Initializing...please wait
Register Failed
Welcome Welcome Welcome
Registering
