CONNECTING TO MONITORS*
Use the diagram below to connect to a Monitor or CRT Monitor properly.
12VDC
Monitor
Power Connection - 12VDC
All cameras are equipped with a second video output for on-site configuration.
All manuals and user guides at all-guides.com
CCTV Monitor
9
