- Page 1 VELOCICALC ® AIR VELOCITY METER MODEL 9515 OPERATION AND SERVICE MANUAL P/N 1980555, REVISION F NOVEMBER 2020 0.561.8187 information@itm. www. .com...
- Page 2 0.561.8187 information@itm. www. .com...
- Page 3 Copyright TSI Incorporated / 2007–2020 / All rights reserved. LIMITATION OF WARRANTY AND LIABILITY (effective February 2015) Seller warrants the goods, excluding software, sold hereunder, under normal use and service as described in the operator's manual, to be free from defects in workmanship and material for 24 months, or if less, the length of time specified in the operator's manual, from the date of shipment to the customer.
- Page 4 BUSINESS INTERRUPTION, OR ANY SPECIAL, INDIRECT, CONSEQUENTIAL OR INCIDENTAL DAMAGES. SELLER SHALL NOT BE RESPONSIBLE FOR INSTALLATION, DISMANTLING OR REINSTALLATION COSTS OR CHARGES. No Action, regardless of form, may be brought against Seller more than 12 months after a cause of action has accrued.
-
Page 5: Table Of Contents
CONTENTS CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION .... 1 CHAPTER 2 SETTING-UP ..............3 ® Supplying Power to the Model 9515 VelociCalc Air Velocity Meter ....................3 Installing the Batteries ............... 3 Using The Telescoping Probe ............3 Extending The Probe ..............3 Retracting The Probe .............. -
Page 6: Chapter 1 Unpacking And Parts Identification
Chapter 1 Unpacking and Parts Identification Carefully unpack the instrument and accessories from the shipping container. Check the individual parts against the list of components below. If anything is missing or damaged, notify ® Incorporated immediately. 1. Carrying case 2. Instrument 0.561.8187 information@itm. -
Page 7: Chapter 2 Setting-Up
Chapter 2 Setting-up ® Supplying Power to the Model 9515 VelociCalc Velocity Meter The Model 9515 is powered with four size AA batteries. Installing the Batteries Insert four AA batteries as indicated by the diagram located on the inside of the battery compartment. The Model 9515 is designed to operate with either alkaline or NiMH rechargeable batteries, although it will not recharge NiMH batteries. -
Page 8: Chapter 3 Operation
Chapter 3 Operation Keypad Functions ON/OFF Key Press to turn the Model 9515 on and off. During the power up sequence the display will show the following: Model Number, Serial Number, Software Revision, and Last Date Calibrated. ft/min / m/s Key Pressing this key changes the display to read air velocity. -
Page 9: Chapter 4 Maintenance
Chapter 4 Maintenance The Model 9515 requires very little maintenance to keep it performing well. Recalibration ® To maintain a high degree of accuracy in your measurements, TSI ® recommends that you return your Model 9515 to TSI Incorporated for annual recalibration. Please contact one of TSI’s offices or your local distributor to make service arrangements and to receive a “Service Request”... -
Page 10: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Table 5-1 lists the symptoms, possible causes, and recommended solutions for common problems encountered with the Model 9515. If your symptom is not listed, or if none of the solutions solves your ® problem, please contact TSI Incorporated. -
Page 11: Appendix A Specifications
Appendix A Specifications Specifications are subject to change without notice. Velocity: Range: 0 to 4000 ft/min (0 to 20 m/s) 1&2 Accuracy ±5% of reading or ±5 ft/min (±0.025 m/s), whichever is greater Resolution: 1 ft/min (0.01 m/s) Temperature: Range: 0 to 200°F (-18 to 93°C) Accuracy ±0.5°F (±0.3°C)
