BLACKMER POWER PUMPS
INSTALLATION OPERATION AND MAINTENANCE INSTRUCTIONS
®
ProVane
Models: PVS10A, 15A, 20A, 30A, 40A, 50A
Patent Protected by U.S. Patents 6030191, 7134855
TABLE OF CONTENTS
General Safety Data................................................1-2
Initial Pump Start Up Information................................2
Technical Data ...........................................................2
Pre-Installation Cleaning ............................................3
Location and Piping....................................................3
Mounting ....................................................................4
Coupling Alignment ....................................................4
Pump Rotation............................................................4
To Reverse Pump Flow..............................................4
Check Valves .............................................................4
Pre-Start Up Check List..............................................5
Start Up Procedures...................................................5
Running the Pump in Reverse....................................5
Flushing the Pump .....................................................6
Optional Pump Relief Valve........................................6
Torque Table.................................................................8
Lubrication.....................................................................8
Strainers........................................................................8
Vane Replacement........................................................8
Pump Disassembly .......................................................9
Parts Replacement........................................................9
Pump Assembly ..........................................................10
Liner Intake & Discharge Identification ........................11
TROUBLE SHOOTING ......................................................13
This is a SAFETY ALERT SYMBOL.
When you see this symbol on the product, or in the manual,
look for one of the following signal words and be alert to the
potential for personal injury, death or major property damage
Warns of hazards that WILL cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause personal injury
or property damage.
NOTICE:
Indicates special instructions which are very
important and must be followed.
& 7316551 B2 an
Page
ONLY Pump models listed below are covered in this Manual
Single Liner Models
PVS10A, 15A
PVS20A, 30A
PVS40A, 50A
Blackmer manuals and parts lists may be obtained from
Blackmer's website (www.blackmer.com) or by contacting
Blackmer Customer Service.
Numbers in parentheses following individual parts indicate
reference numbers on Blackmer Part Lists.
SAFETY DATA
Blackmer Pumps MUST only be installed in systems, which
have been designed by qualified engineering personnel. The
system MUST conform to all applicable local and national
regulations and safety standards.
This manual is intended to assist in the installation and
operation of the Blackmer ProVane pumps, and MUST be
kept with the pump.
Pump service shall be performed by qualified technicians
ONLY.
Service shall conform to all applicable local and
national regulations and safety standards.
Thoroughly review this manual, all instructions and hazard
warnings, BEFORE performing any work on the pump.
Maintain ALL system and pump operation and hazard
warning decals.
965830
Page 1/16
INSTRUCTIONS NO. 111-G00
Section
111
Effective
Oct 2008
Replaces
Dec 2007
d Related Foreign Patents.
Material
Stainless Steel
Stainless Steel
Stainless Steel
NOTICE:
Parts List
111-G01
111-G02
111-G03
