Related Manuals for Gorenje FHE302W
Summary of Contents for Gorenje FHE302W
- Page 1 Instructions for use Gebrauchsanweisung Gebruiksaanwijzing Freezer chest Gefriertruhe Diepvrieskist...
-
Page 2: Table Of Contents
Freezer chest We thank you for the confi dence you have shown by purchasing our appliance. We wish you fi nd a lot of pleasure in its use. The appliance is intended solely for household use. The freezer chest is intended for use in household, for freezing fresh food and long-term storage of frozen food (up to one year, depending on the type of food). -
Page 3: Before Using The Appliance For The Fi Rst Time
Before using the appliance for the fi rst time • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 The appliance is fi tted with a condenser unit which radiates heat into the environment. The condenser unit is installed on the back wall, directly underneath the sheet metal layer of the back and front wall of the appliance. During normal operation, these surfaces are warm.
-
Page 5: Advice For Saving Power
Advice for saving power • Install the appliance as specifi ed in the instruction manual. • Do not open the appliance cover ore often than necessary. • In models with condenser units on the back wall of the appliance, check occasionally to make sure that air circulation behind the appliance is indeed unobstructed and that the condenser unit is always clean (see section “Troubleshooting”). -
Page 6: Installation And Connection
Food storage time in • In case of a fault in appliance operation or power supply case of fault or power failure, do not open the freezer chest. If the appliance is out of failure order for more than two days, empty the freezer and use the food or make sure it remains frozen. - Page 7 Air circulation around • The appliance should not be integrated in a cupboard or other the appliance furniture. Allow at least 2-3 centimetres of clearance around the chest for free circulation of air. • With models with a visible condenser unit installed on the back wall, make sure the clearance from the wall is at least 70 mm (see fi...
-
Page 8: Operating The Appliance
Operating the appliance CONTROL UNIT I CONTROL UNIT II A Temperature settings knob – Switching the appliance on/off – Activating the super freeze function B Signal light on: Super freeze function is activated C Signal light on: The appliance is powered (there is voltage in the appliance) D Signal light on/ fl... - Page 9 Control unit I: When the appliance is switched on for the fi rst time, the D signal light will be on. It will go off automatically when the freezer cools down to a temperature that no longer presents danger of food spoilage.
- Page 10 Signal light D will be on/will fl ash when the temperature in the freezer rises to a level that is too high, and goes off when the temperature drops back to a level that no longer represents food spoilage hazard (see section »Troubleshooting«). Starting up the appliance Switch on the appliance and rotate the thermostat knob to the intensive freezing (»super freeze«) position...
- Page 11 Freezing process • Activate the super freeze function 24 hours before freezing fresh food: - rotate the A button to the position (signal light B will light - insert fresh food into the freezing compartment. Before placing the food in the appliance, cool it to room temperature.
-
Page 12: Defrosting And Cleaning The Appliance
Approximate storage time for frozen food Type of food Storage time (months) Vegetables Fruit Bread, pastry Milk Prepared food dish Meat: beef Veal Pork Poultry Venison Chopped Smoked sausage Fish: lean Entrails Defrosting and cleaning the appliance Defrosting the appliance •... - Page 13 Removing frost by thawing If the frost layer is too thick to be scraped off, it has to be at least partially melted. • Remove the plug (1) on the front side of the freezer. • Insert the supplied tube into the opening (2) an place a container to collect the water from the melted frost underneath it.
-
Page 14: Troubleshooting
Troubleshooting Faults may appear during appliance operation. Following is a list of some faults that are most commonly the result of improper use and which you can fi x yourself. Problem Cause Remedy After connecting to the mains, the The outlet/socket is not powered. appliance does not work. - Page 15 They are not suitable for household room illumination. WE RESERVE THE RIGHT TO CHANGES THAT DO NOT AFFECT THE APPLIANCE FUNCTIONALITY. Instructions for use of the appliance can also be found on our website at www.gorenje.com / < http://www.gorenje.com />...
