EN
DETAILED
INSTRUCTIONS FOR
USE OF UPRIGHT
FREEZER
www.gorenje.com
www.gorenje.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje FS600

Summary of Contents for Gorenje FS600

  • Page 1 DETAILED INSTRUCTIONS FOR USE OF UPRIGHT FREEZER www.gorenje.com www.gorenje.com...
  • Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in its use. The appliance is intended solely for household use. The freezer is intended for freezing fresh food and for long-term storage of frozen food (up to one year, depending on the type of food).
  • Page 3 TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND WARNINGS ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE APPLIANCE DESCRIPTION DESCRIPTION INSTALLATION AND CONNECTION 12 CHANGING THE DIRECTION OF DOOR OPENING 14 OPERATING THE APPLIANCE WITH ELECTRONIC CONTROLS 20 APPLIANCE INTERIOR EQUIPMENT STORING AND 21 FREEZING AND STORING FROZEN FOOD FREEZING FOOD...

  • Page 4: Important Notes And Warnings

    IMPORTANT NOTES AND WARNINGS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 5 Before connecting the appliance to the power mains, let the appliance rest in a vertical position for approximately 2 hours. This will reduce the possibility of operation faults due to the effect of transport on the cooling system. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations.
  • Page 6 appliance to an authorized home appliance collection center. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Rating plate can be found in the appliance interior. If the language on the rating plate is not the language of your choice or the language of your country, replace it with the one supplied.

  • Page 7: Advice For Saving Power With Refrigeration Appliances

    ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).

  • Page 8: Appliance Description

    APPLIANCE DESCRIPTION NO FROST FREEZER Control unit 2 Led lighting of freezer interior 3 NO FROST freezing unit (cooler, fan ...) 4 Freezing and storage compartment 5 Foot • Appliance interior equipment may change according to the appliance model. • The drawers are protected against pulling out. To remove a drawer from the appliance, open it, then lift the front part and pull it out.

  • Page 9: Installation And Connection

    INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Temperature SN (subnormal)
  • Page 10 • The appliance may stand alone or it may be placed ext to a cupboard or a wall. Consider the clearance required to fully open the door in order to allow pulling out the drawers and shelves (see installation diagram). 600 mm 644 mm...

  • Page 11: Connecting The Appliance

    Note: When placing the appliances side by side, the anti-dew (anti-condensation) set has to be purchased and installed! dry room (relative humidity below 60%) Code for ordering the set METAL PLATE (INOX) 576604 PLASTIC PLATE WHITE 672114 GREY 672115 BLACK 672116 humid room (relative humidity over 60%)* Code for ordering the set...

  • Page 12: Changing The Direction Of Door Opening

    CHANGING THE DIRECTION OF DOOR OPENING Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, flat screwdriver The procedure to change the direction of door opening should be carried out by at least two persons. 1. Remove the upper hinge cover (A) and the covering cap (G). 2.

  • Page 14: Operating The Appliance With Electronic Controls

    OPERATING THE APPLIANCE WITH ELECTRONIC CONTROLS CONTROL UNIT 1 A Knob for temperature settings, switching the appliance on/off , and activating the super freeze function SWITCHING THE APPLIANCE ON/OFF To switch on: rotate the thermostat knob A clockwise towards the thicker end of the sign.

  • Page 15: Adjusting The Temperature

    ADJUSTING THE TEMPERATURE • To set the desired temperature, rotate the A dial in clockwise direction, i.e. to the right. • Recommended setting of the A knob is on the eco position. • A change in the environment temperature will aff ect the temperature in the appliance.
  • Page 16 CONTROL UNIT 2 A Temperature setting and on/off dial Use the dial to switch the appliance on or off , set the temperature, and control the ECO and intensive freezing (freezer boost) function. B Temperature display It displays the currently set temperature in the refrigerator compartment. SWITCHING THE APPLIANCE ON/OFF Switching on: To switch on: rotate the A dial clockwise.
  • Page 17 ADJUSTING THE TEMPERATURE IN THE APPLIANCE • After the appliance is switched on, it may take several hours for the set temperature to be reached. Do not place any food into the refrigerator before the temperature drops to the selected setting. •...
  • Page 18 CONTROL UNIT 3 A On/off switch B Temperature adjustment and freezer boost key C Freezer temperature display D Freezer boost function indicator SWITCHING THE APPLIANCE ON/OFF Press the A key to switch the appliance on/ off.
  • Page 19 ADJUSTING THE TEMPERATURE IN THE APPLIANCE • Adjust the temperature as desired with the B key. • Set the desired temperature, indicated on the display, by successively pressing the B key. • Recommended temperature setting is -18°C. FREEZER BOOST (SUPER FREEZE) FUNCTION To activate the freezer boost function, press the B key until the symbol D lights up.

  • Page 20: Appliance Interior Equipment

    APPLIANCE INTERIOR EQUIPMENT (* only in some models) MULTIBOX STORAGE BIN/ICE TRAY* • The MultiBox bin is convenient for storing food with a strong or pungent smell. • The silicone lid provides an air-tight seal that prevents the food from drying out and the odour to spread throughout the refrigerator compartment.

  • Page 21: Freezing And Storing Frozen Food

    FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;...

  • Page 22: Frozen Food Storage Time

    • Freezer models NO FROST allow freezing in all drawers, but not more than 7 kg in any particular drawer, and 4 kg in the bottom drawer. IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh.

  • Page 23: Defrosting The Appliance

    DEFROSTING THE APPLIANCE DEFROSTING A NO FROST FREEZER • The NO FROST freezer will defrost automatically. Occasional frost that may appear on the walls will disappear automatically. • Build-up of ice or frost in the freezer compartment can be a result of abnormal use of appliance (door opened too frequently and/or too long, door not properly closed etc.).

  • Page 24: Cleaning The Appliance

    CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface.

  • Page 25: Troubleshooting

    TROUBLESHOOTING Problem: Cause or remedy: Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. Cooling system operates • Too high environment temperature. continuously for a long •...

  • Page 26: Information About Appliance Noise

    WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.gorenje. com / < http://www.gorenje.com />...
  • Page 28 FREEZER_FS600_ESSENTIAL en (09-17)
