Chest-type Freezer
Thank you for your trust and for buying
this appliance.
We hope it will successfully serve the
purpose for many years.
The chest-type freezer for domestic use is
intended for freezing of fresh articles of
Before Using .................................................. 18
Instructions for Use
We Care for the Environment
Energy Saving
Important....................................................... 19
Storage Time in Case of Defect or Cutout
of Power Supply
Disposing of the Worn Out Appliance
Installation ..................................................... 20
Selection of Room
Cooling of the Appliance
Connection to the Mains Supply
Operating the Appliance .............................. 20
Temperature Selection
Before Using
• Before connecting the appliance to the
mains supply, leave it to rest in its place
for about 2 hours. In this way you reduce
a possibility of troubles occurring in
cooling system due to transport
handling.
• Remove the two plastic spacers which
are situated under the lid and protecting
the seal against damages
during transport.
• Clean the interior of the appliance with
lukewarm water into which you have
added a few drops of vinegar or baking
soda (1 tablespoon per 1 liter of water).
Instructions for Use
These instructions for use are intended for
the user of the appliance.They describe
the appliance and its correct and safe use.
They relate to various types of freezers
therefore you will find among them also
those functions which do not apply to your
appliance.
18
Downloaded from Fridge-Manual.com Manuals
food and for long-term storage of frozen food
(up to one year), depending on the kind of
food.
The temperature in the interior is –18°C or
lower.
Red Light
ON/OFF Switch
Interior Light (on some models only)
Use................................................................... 22
Operation Modes
Switching on the Empty Freezer
Freezing of Fresh Foods
Storage of Frozen Foods
Frozen Food Defrosting
Cleaning and Maintenance ........................... 24
Freezer Defrosting
Cleaning
Discontinued Service
Trouble-shooting Guide ................................ 25
We Care for the Environment
Our products use environmentally friendly
packaging, which can be either recycled or
disposed of in an environmentally friendly
manner. To this end, individual packaging
materials are clearly marked.
These instructions are printed either on
recycled paper or chlorine free bleached
paper.
When your appliance finally wears out,
please try not to burden the environment
with it; call your nearest authorised service
agent. (See Disposing of the Worn Out
Appliance)
Energy Saving
• Do not open the lid more frequently than
it is necessary as too frequent openings
of the lid cause temperature rises in the
freezer, excessive formation of frost and
consequently higher energy
consumption.
• Take care not to leave the lid open too
long, particularly if the ambient air is hot
and humid.
Instructions for Use
EN
Advertisement
Table of Contents
Related Manuals for Gorenje FH 13400 W
Summary of Contents for Gorenje FH 13400 W
-
Page 1: Before Using
Chest-type Freezer Thank you for your trust and for buying food and for long-term storage of frozen food this appliance. (up to one year), depending on the kind of We hope it will successfully serve the food. purpose for many years. The temperature in the interior is –18°C or The chest-type freezer for domestic use is lower. - Page 2 • It is recommendet to remove the frost • The condenser on the rear wall should layer when it is 3 to 5 mm thick. be always clean, free of dust or any • Before loading the appliance with impurities. •...
-
Page 3: Installation
break it, in order to prevent eventual Storage Time in Case of Defect or accidents (danger of children get locked Cutout of Power Supply inside the appliance). The refrigerating system of the appliance is filled with In case of defect or cutout of power supply, refrigerant and insulating substances which do not open the freezer. -
Page 4: Operating The Appliance
Operating the Appliance The freezer is controlled by two switches automatic operation (switch covers yellow) and thermostat knob. The switches are lightcontinuous incorporated in the front or in the lid of the operation (yellow light is on) freezer. 4 Green light 5 Yellow light Switches (feature depends on the model) -
Page 5: Red Light
Interior Light (on some models only) The interior light is on when the freezer lid is opened. It is on even the appliance is switched off (green light off). Higher settings on the knob (towards 6) mean lower temperatures (colder) in the NOTE: freezer. -
Page 6: Storage Of Frozen Foods
and that food is cooled down before putting Frozen Foods Storage Time into the freezer. Frozen food storage time is the period in which a frozen food still preserves its initial 1. Freezing procedure quality or better the period in which One day before freezing of foods place the microbiological and biochemical switch on the position for continuous... -
Page 7: Cleaning And Maintenance
Approximate Storage Time of Frozen Foods Food Storage time (in months) Vegetable Fruit Braed, Pastries Milk Redy-made meals Meat: Beef Veal Pork Poultry Game Minced meat Smoked sausages Fish: lean Offal Cleaning and Maintenance Freezer Defrosting Frost Layer Defrosting • When the frost layer is too thick to be •... -
Page 8: Discontinued Service
Be careful to remove any cleanser agent Discontinued Service remaining after cleaning. • Before cleaning the appliance disconnect Disconnect the cable from the mains supply, the cable from the mains supply! empty the foods, defrost and clean the • Wash the inside surfaces with lukewarm interior. -
Page 9: Troubleshooting Guide
Trouble-shooting Guide During the service, the user come across troubles, which in most cases result from troubles appearing during the operation of improper handling of the appliance and can the appliance. We are listing some of be eliminated by yourself. Trouble Cause Trouble-shooting...
