Introduction

1. Introduction
The AYC-Q65 is a vandal-resistant, waterproof, standalone,
convertible integrated reader and controller with a piezoelectric
keypad. The AYC-Q65 automatically determines whether to function
as a reader or as a controller. If the unit is connected to a standard
access control unit, then it functions as a reader. If the unit is
connected to Rosslare's secure application appurtenances such as the
PS-A25T, PS-C25T or PS-C25TU, it functions as a secured controller.
The unit is water resistant and suitable for indoor or outdoor
mounting. As a controller, the unit accepts up to 500 users, and
allows entry via a personal identification number (PIN) or by
presenting a proximity card. The PIN code length for the controller has
several options. The PIN code length can be a set number of 4, 5, or 6
digits or it can be a 4-8 digits option.
For information on how the unit functions as a reader, see Chapter 4.
For information on how the unit functions as a controller, see Chapter
5.
1.1

Key Features

The key features for the AYC-Q65 are:

Built-in proximity card reader (125 kHz ASK modulation)

Built-in piezoelectric keypad for PIN code entry

Programmable patented blue backlit keypad

Optical back tamper sensor and open collector tamper output

Lockout feature on wrong entries (keypad/card tamper)

Internal buzzer provides audible interface feedback

Two status/programming interface LEDs (tri-colored)

Fully potted construction for outdoor use

Comes with mounting template for easier installation

Comes with an installation kit that includes a security screw and a
security screw tool
AYC-Q65 Installation and Programming Manual 9
