WORKING LOAD LIMIT 1400KG
• Safety Instructions
• Operation Procedures
• Maintenance Procedures
READ RULES FOR SAFE OPERATION
AND INSTRUCTIONS CAREFULLY
AND INSTRUCTIONS CAREFULLY
WARNING:THEJACKMUSTBEUSEDONLYONHARD
LEVEL SURFACES AND BE FREE TO ROLL DURING
LIFTING AND LOWERING. DO NOT GET UNDER A
VEHICLE THAT IS SUPPORTED BY A TROLLEY JACK
- USE SUPPORT STANDS.
FLOOR JACK
OWNER'S MANUAL
THIS NEW JACK CONFORMS TO MANDATORY
AS/NZS2615:2004 STANDARD
Shinn Fu (Australia) PTY. LTD.
15 Viewtech Place, Rowville, Victoria 3178, Australia
Model: F1400
1
Advertisement
Table of Contents
Related Manuals for Pro-Lift F1400
Summary of Contents for Pro-Lift F1400
- Page 1 Model: F1400 FLOOR JACK OWNER’S MANUAL WORKING LOAD LIMIT 1400KG • Safety Instructions • Operation Procedures • Maintenance Procedures READ RULES FOR SAFE OPERATION AND INSTRUCTIONS CAREFULLY AND INSTRUCTIONS CAREFULLY WARNING:THEJACKMUSTBEUSEDONLYONHARD LEVEL SURFACES AND BE FREE TO ROLL DURING LIFTING AND LOWERING. DO NOT GET UNDER A VEHICLE THAT IS SUPPORTED BY A TROLLEY JACK - USE SUPPORT STANDS.
- Page 2 SAFETY INSTRUCTIONS INSPECTIONS This hydraulic trolley jack is designed to be used with a 60mm diameter head cap. 1. BEFORE EACH USE Visual inspection should be made before each use of the trolley jack for abnormal conditions such as cracked welds, leaks and damaged, loose, or missing parts. 2.
- Page 3 OPERATION PROCEDURES Before using Moving the jack 1. Remove cover plate (friction fi t, easily Place handle in Handle Sleeve. DO NOT removes) and open Oil Filler Plug to move the jack when handle is on the allow air to be vented. Release Valve as this may cause damage 2.
- Page 4 SPECIFICATIONS Working Load Limit : ..................1400Kg Jack Dimension : ............... 445mm x 202mm x 135mm Height Lowered : ....................135mm Height Raised : ....................330mm Oil Capacity : ....................70+/-5cc Net Weight : ..................8.6Kg. (approx.) 40mm 65mm 180mm 445mm MAINTENANCE PROCEDURES MAINTAINING OIL LEVEL Important Note: Important Note: 12mm below valve hole.
- Page 5 LUBRICATION KNOW YOUR JACK • Add lubrication oil to all moving parts Compare these illustrations with your every 3 months. jack before operation and/or oil level maintenance to become familiar with PREVENTING RUST the location of jack components. • Check Piston Rod & Pump Piston every 3 months for any signs of rust or OIL FILLER corrosion.
