Operating Instructions & Parts Manual
Model Number
F-2330BMC
Lifting range for Floor Jack: 5-1/4" ~ 13"
Support range for Jack Stands (per pair): 10-1/2"~16-3/4"
To avoid crushing and related injuries:
• NEVER work on, under or around a
load supported only by a hydraulic jack.
• ALWAYS use a pair of appropriately
rated jack stands.
SFA Companies, Inc.
10939 N. Pomona Ave.
Kansas City, MO 64153
Phone (816)891-6390, Fax (816)891-6599
Floor Jack Combo
WARNING
Hydraulic
Capacity
2 Ton
Printed in China
F-2330BMC-M0_012019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pro-Lift F-2330BMC
Summary of Contents for Pro-Lift F-2330BMC
- Page 1 Floor Jack Combo Operating Instructions & Parts Manual Capacity Model Number 2 Ton F-2330BMC Lifting range for Floor Jack: 5-1/4” ~ 13” Support range for Jack Stands (per pair): 10-1/2”~16-3/4” WARNING To avoid crushing and related injuries: • NEVER work on, under or around a load supported only by a hydraulic jack.
-
Page 2: Product Description
(See Replacement Parts Section). Lubricate as instructed in Maintenance PRODUCT DESCRIPTION Section. Pro-Lift Floor Jack is designed to lift, but not sustain, rated capacity loads. It is designed to be used in conjunction with jack stands. Pro-Lift Floor Jack has a unique feature which provides fast, no load lifts to the jacking point. - Page 3 WARNING ADVERTENCIA Study, understand, and follow all Estudie, entienda y sega todoslos instructions before operating this materiales impresos con / para este device. Do not exceed rated capacity. producto antes de su uso. No exceda Use only on hard, level surface. Lifting la capacidad nominal.
-
Page 4: Operation
OPERATION Lowering Lifting (refer to Fig 1) 1. Place vehicle in park, with emergency 1. Raise load high enough to clear jack b r a k e o n a n d w h e e l s s e c u r e l y stands, then carefully remove jack chocked to prevent inadvertent vehicle stands. -
Page 5: Maintenance
MAINTENANCE MAINTENANCE (continued) Important: Use only a good grade 2. Lay the jack on its side and drain the hydraulic jack oil (e.g. Mobil DTE 13M or fluid into a suitable container. equivalent). Avoid mixing different types Note: Dispose of hydraulic fluid in of fluid and Never use brake fluid, turbine accordance with local regulations. -
Page 6: Replacement Parts
When ordering parts, give model number, serial number and description below. Call or write for current pricing: phone (816) 891-6390, fax (816) 891-6599 or contact Pro-Lift Customer Support, 10939 N. Pomona Ave., Kansas City, MO 64153. - Page 7 PRODUCT DESCRIPTION ratchet bar locking Pro-Lift Jack Stands are designed to handle stopper safely support level, rated capacity loads, typically vehicles, for extended periods. Stamped steel construction and ductile press tab...
- Page 8 WARNING ADVERTENCIA Study, understand, and follow all Estudie, entienda sega todos instructions before operating this los materiales impresos con / para device. Do not exceed rated capacity. este producto antes de su uso. ¡ La Use only on hard, level surface. Center capacidad normal es por el par! No load on saddle.
- Page 9 OPERATION To lower load 1. With suitable jack, raise vehicle clear 1. Adjust height by pulling up on ratchet of stands. bar. 2. Carefully release stopper and allow 2. The weight of the locking handle ratchet to glide down to lowest should secure the ratchet bar in desired position.
-
Page 10: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year days from date of purchase, SFA Companies, Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage. - Page 11 NOTE PAGE / NOTES / NOTAS SFA Companies, Inc. 10939 N. Pomona Ave. Kansas City, MO 64153 Tel. (888) 332-6419, Fax (816) 891-6599...
- Page 12 NOTE PAGE / NOTES / NOTAS SFA Companies, Inc. 10939 N. Pomona Ave. Kansas City, MO 64153 Tel. (888) 332-6419, Fax (816) 891-6599...
