WORKING LOAD LIMIT 2000KG
• Safety Instructions
• Operation Procedures
• Maintenance Procedures
READ RULES FOR SAFE OPERATION AND INSTRUCTIONS CAREFULLY
WARNING:THEJACKMUSTBEUSEDONLYONHARD
LEVEL SURFACES AND BE FREE TO ROLL DURING
LIFTING AND LOWERING. DO NOT GET UNDER A
VEHICLE THAT IS SUPPORTED BY A TROLLEY JACK
- USE SUPPORT STANDS.
15 Viewtech Place, Rowville, Victoria 3178, Australia
FLOOR JACK
OWNER'S MANUAL
THIS NEW JACK CONFORMS TO MANDATORY
ASNZS 2615:2004 STANDARD
Shinn Fu (Australia) PTY. LTD.
Model: F2000
1
Advertisement
Related Manuals for Pro-Lift F2000
Summary of Contents for Pro-Lift F2000
- Page 1 Model: F2000 FLOOR JACK OWNER’S MANUAL WORKING LOAD LIMIT 2000KG • Safety Instructions • Operation Procedures • Maintenance Procedures READ RULES FOR SAFE OPERATION AND INSTRUCTIONS CAREFULLY WARNING:THEJACKMUSTBEUSEDONLYONHARD LEVEL SURFACES AND BE FREE TO ROLL DURING LIFTING AND LOWERING. DO NOT GET UNDER A VEHICLE THAT IS SUPPORTED BY A TROLLEY JACK - USE SUPPORT STANDS.
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS INSPECTIONS 1. BEFORE EACH USE Visual inspection should be made before each use of the trolley jack for abnormal conditions such as cracked welds, leaks and damaged, loose, or missing parts. 2. AFTER EACH USE Trolley jack should be inspected immediately if the lift is believed to have been subjected to an abnormal load or shock. -
Page 3: Operation Procedures
OPERATION PROCEDURES Before using Moving the jack 1. Remove cover plate (friction fit, easily Place handle in Handle Sleeve. DO NOT removes) and open Oil Filler Plug to move the jack when handle is on the allow air to be vented. Release Valve as this may cause damage 2. -
Page 4: Specifications
SPECIFICATIONS Working Load Limit: ................... 2000Kg Jack Dimension : ..............595mm x 188mm x 165mm Height Lowered : ....................150mm Height Raised : ....................425mm Oil Capacity : ......................165ml Net Weight : ..................14.9Kg. (approx.) 40mm 76mm 188mm 595mm MAINTENANCE PROCEDURES MAINTAINING OIL LEVEL Important Note: 12mm below valve hole. -
Page 5: Troubleshooting
LUBRICATION KNOW YOUR JACK • Add lubrication oil to all moving parts Compare these illustrations with your every 3 months. jack before operation and/or oil level maintenance to become familiar with PREVENTING RUST the location of jack components. • Check Piston Rod & Pump Piston every 3 months for any signs of rust or OIL FILLER corrosion.
