INSTALLATION GUIDE
WILLO II RAIN SHOWER COLUMN W2RSCC
SYSTEM REQUIREMENTS
To ensure the optimum performance and customer satisfaction please adhere to the following:
• Flush out all pipe work prior to installation.
• Maximum hot water temperature is 60˚C. If the water temperature exceeds 60˚C an approved tempering valve
must be fitted.
• Installation should comply with relevant local authority requirements.
• In accordance with good plumbing practice, filters should be fitted to supply lines to eliminate damage to the
ceramic cartridge from suspended solids.
• AS/NZS 3500.1 states that pressures above 500kPa can cause damage from water hammer, reduce the life of
appliances, taps & fittings, cause excessive noise in the system and recommend that a pressure limiting valve
(PLV) be fitted.
MAXIMUM STATIC PRESSURE
Maximum static pressure 500kPa. If water
pressure exceeds or is likely to exceed
500kPa, an approved pressure limiting valve
must be fitted.
Failure to comply with the above will void warranties.
WHAT IS IN THE PACK
2 x Wall Anchors 2 x Screws
2 x Flow Restrictor
Top Mounting Bracket +
& Sleeve
1 x Hose
Bottom Mounting Bracket
Chrome Flange + Chrome Flange
(Diverter Valve)
MINIMUM STATIC PRESSURE
Minimum static pressure 150kPa. To ensure
optimal performance the static pressure must
be greater or equal to 150kPa.
1 x Rain Head
1 x Single Spray
Handpiece
1 x Slider
1 x Rail & Arm
