I N S T A L L A T I O N
Flat Panel Display Security Kit
(FSA-1009 and KSA-1009)
The flat panel display security kit replaces exposed
hardware with security hardware.
NOTE: In some installations (i.e. single arm mount) not
all fasteners included in this kit will be required.
The security accessory kit can be used on most flat
panel configurations.
The pivot/pitch mount and mounts that are equipped with
a swing arm use the 4-inch security pivot bolts. Mounts
that are equipped with a height-adjustable arm use the
5-inch security pivot bolts. Some configurations can use
both the 4-inch and 5-inch security pivot bolts.
The security accessory kit is available for F-Series
mounts and K-Series mounts.
BEFORE YOU BEGIN
CAUTION: To prevent damage to the mount, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install the mount brackets. Pay particular
attention to the "Important Warnings and Cautions" on Page 2.
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280.
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX 952-894-6918
8401 EAGLE CREEK PARKWAY, STE. 700
SAVAGE, MINNESOTA 55378 USA
I N S T R U C T I O N S
Security Parts Kit
8807-000025 (Rev. C)
©2006 Chief Manufacturing
www.chiefmfg.com
06/06
Advertisement
Table of Contents
Related Manuals for CHIEF Flat Panel Display Security Kit FSA-100
Summary of Contents for CHIEF Flat Panel Display Security Kit FSA-100
-
Page 1: Before You Begin
Pay particular attention to the “Important Warnings and Cautions” on Page 2. If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280. CHIEF MANUFACTURING INC. - Page 2 Installation Instructions IMPORTANT WARNINGS and CAUTIONS! WARNING A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corresponding instructions.
-
Page 3: Table Of Contents
Installation Instructions CONTENTS TOOLS REQUIRED FOR INSTALLATION ...3 PARTS...3 DISPLAY SECURITY SCREWS...4 Flush Mount...4 Recessed Mount...4 INSTALL SECURITY PIVOT BOLTS...5 Install 4-inch Security Pivot Bolts ...5 Install 5-inch Security Pivot Bolts ...5 Install 4-inch and 5-inch Security Pivot Bolts ...5 INSTALL SECURITY SET SCREWS...6 Option I...6 Option II...6... -
Page 4: Display Security Screws
Installation Instructions DISPLAY SECURITY SCREWS Select the appropriate hardware from the security kit to secure your display. Select the procedure, listed below, that applies to your application. Flush Mount (no spacers required) Recessed Mount (spacers required) Flush Mount 1. Verify that you have the correct parts. 2. -
Page 5: Install Security Pivot Bolts
Installation Instructions INSTALL SECURITY PIVOT BOLTS Perform the applicable procedure to replace the regular pivot bolts with security pivot bolts. You will need the security hex keys (provided) to complete the installation. Install 4-inch Security Pivot Bolts For swing arm models, replace the standard pivot bolts with security pivot bolts, as follows: NOTE: Do not remove the display (not shown) from the Centris mount. -
Page 6: Install Security Set Screws
Installation Instructions INSTALL SECURITY SET SCREWS The security set screw is used to secure the pivot-pitch wall mount. You will need the security hex keys (provided) to install the security set screws. There are two different wall plates, which require different security requirements.
