- Page 1 INSTALLATION AND USER MANUAL MODELS AR-60-903BL AR-60-903SS AR-90-903BL AR-90-903SS...
- Page 2 Warranty and service certificate: This certificate is issued by Falco Domestic Appliances, supplier of ALL Unbranded Falco Extractor fan models. Hereinafter referred to as ‘The Company’, to the original purchaser only, of the product/appliances described on the certificate and shall constitute the only warranty given in respect of this product/appliance.
- Page 3 Alternatively using the following link: www.falco.co.za/service. Any service-related queries should be directed directly to the dealer (store) where the unit was purchased. Alternatively, the purchaser can contact the appointed call centre on the details provided above.
-
Page 4: Table Of Contents
Table of Contents INTRODUCTION............................5 SAFETY PRECAUTIONS..........................5 INSTALLATION............................5 AIR VENTILATION SETTING ........................7 OPERATION..............................8 MAINTENANCE ............................9 TROUBLESHOOTING..........................11 FREQUENTLY ASKED QUESTIONS ......................12 ENVIRONMENTAL PROTECTION........................15... -
Page 5: Introduction
INTRODUCTION This instruction manual is designed to provide you with all the required instructions related to the installation, use and maintenance of the appliance. In order to operate the unit correctly and safety, please read this instruction manual carefully before installation and usage. This extractor makes use of high quality materials and is made with a streamlined design. - Page 6 Drawing A. 2. The extractor should be mounted at the following distances above the counter top: Above a gas hob or cooker – 75cm, but not exceeding 75cm. Above an electrical hob or cooker – 65cm, but not exceeding 75cm.
-
Page 7: Air Ventilation Setting
2. Attach the plastic non-return valves on top of the extractor. (No: A in drawing C on page 4) OPTION 2 (Installing with a cupboard above the unit) 1. Attach a ducting pipe to the top of the non-return valve on top of the extractor (if ducting out using a ducting pipe). -
Page 8: Operation
If recirculating the air back into the kitchen space by making use of the carbon cloth filter, turn the adjuster knob to the indoor position (This can be found on the motor of the extractor, if you remove the aluminium filters). The air will then be vented out the front of the unit. -
Page 9: Maintenance
MEDIUM SPEED BUTTON Airflow speed ideal for standard cooking operation HIGH SPEED BUTTON When high levels of smoke are produced during cooking, press for highest level of extraction. LIGHT BUTTON MAINTENANCE Before cleaning, switch off the unit by unplugging from the wall socket, or if connected directly to the mains, switch off at the isolator switch. - Page 10 BULB REPLACEMENT 1. Switch off the unit and unplug. 2. Remove the lamp cover. 3. Unscrew the incandescent bulb. 4. Replace with the same type and rated bulb. – Tungsten filament lamp –tubular – Max wattage: 28 W – Voltage range: 230 V –...
-
Page 11: Troubleshooting
TROUBLESHOOTING Fault Cause Solution Light comes The fan blade is jammed. Switch off the unit and repair by a qualified service agent. does not work The motor is damaged. Both light and Replace the bulb with correct rating. Light bulb burn. fan does not work Power cord loose... -
Page 12: Frequently Asked Questions
Using the extractor you purchased on any commercial application poses a serious fire risk and will result in immediate void of your warranty. Please contact our Falco offices for assistance with Gas Braai Extractors. 3. Q: What is the correct installation height? A: The recommended installation height is 700mm above gas and 650mm above electrical. - Page 13 A: Yes. Please make sure of your measurements before starting your installation process. Additional bottom chimneys and installation brackets are sold by Lategan & Van Biljoens in Pretoria and they are used to extend the chimneys on Falco units. 13. Q: My extractor is blowing and not extracting? A: There are three main reasons that can cause your extractor to blow instead of extracting and most of the time (98%), this is caused by faulty installations.
- Page 14 A: Full range of spares is available from Lategan & Van Biljoens in Pretoria. www.appliancesspares.co.za 15. Q: What is the diameter of my ducting hose? A: 150mm 16. Q: More Queries? A: Please email any queries to: info@falco.co.za, Tel: 011 454 6423/4314. Spares can be viewed and ordered online: www.appliancespares.co.za...
-
Page 15: Environmental Protection
ENVIRONMENTAL PROTECTION Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this...
