  • Page 2 Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Abetechs GmbH (Grundig Security) reserves the right to change the contents of this document without prior notice. Design and specifications are subject to change without prior notice.
  • Page 3 OPEN SOURCE SOFTWARE LICENSE INFORMATION The software components provided with Grundig products may contain copyrighted software that is licensed under various open source software licenses. For detailed information about the...
  • Page 4 You may obtain the complete corresponding open source part of a specific product from us for a period of three years after our last shipment of this product by sending an email to: info@grundig- security.com Safety and Installation Instruction...
  • Page 5 Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way. If the product starts to smell or smoke comes out of the device, immediately stop using the product and disconnect it from the power supply to prevent fire or electric shocks.
  • Page 6 Do not install the product near heat sources, like radiators or other equipment that produces some heat. If the product is not classified by any IP class, do not install the product in very cold or hot temperatures (please refer to the working temperature specified in the specification sheet of the product), dusty, dirty or damp environment.
  • Page 7 Special Installation Instructions for IP Cameras Make sure that the latest firmware is installed on the IP Device. You may get the latest firmware from www.grundig-security.com website or from techsupport@grundig-security.com.

  • Page 8: Table Of Contents

    3.1 Wiring ................22 3.2 Activating the Camera ........... 23 3.2.1 Activation via Web Browser ........ 23 Activation via Grundig IP-Finder Tool ....24 3.3 Modifying the IP Address ..........26 4 Accessing via Web Browser ............28 4.1 Initializing the Memory Card ......... 30...

  • Page 9: Appearance Description

    1 Appearance Description 1.1 IR Speed Dome Overview Note: The figures below are for reference only, refer to the actual product as the standard. 1.1.1 Overview of the IR Speed Dome Figure 1-1 Overview of the IR Speed Dome...

  • Page 10: Cable Interfaces

    1.2 Cable Interfaces The cable interfaces of the speed dome are shown in Figure 1-2. The cables are distinguished by different colors. Refer to the labels attached on the cables for identification. Notes: Make sure the speed dome is power-off before you connect the cables.

  • Page 11: Alarm Output

    1.3 Alarm Output Alarm output is shown in Figure 1-3. Figure 1-3 Alarm Output...

  • Page 12: Installation

    2 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Notes:  Do not touch the bubble directly by hand. The image blurs otherwise.

  • Page 13: Installing Speed Dome

    Figure 1-3 Do Not Drag the Cables 2.1 Installing Speed Dome 2.1.1 Wall Mounting Notes:  For cement wall, you need to use the expansion screw to fix the bracket. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the bracket.
  • Page 14  Make sure that the wall is strong enough to withstand more than eight times the weight of the speed dome and the accessories.  Water-proof treatment is required for cable connectors. Steps: 1. Install the bracket. Drill four screw holes in the wall according to the holes on the bracket, and then insert four expansion screws into the mounting holes.
  • Page 15 Figure 2-2 Install head cover 3. Hook the speed dome to the bracket with supplied safety rope. Figure 2-3 Use Safety Rope...

  • Page 16: Pole Mounting

    4. Route and connect the cables through the head cover and bracket. Note: Water-proof treatment is required for cable connectors. 5. Align the speed dome with the head cover. Use the wrench to tighten the lock screws. Figure 2-4 Secure the speed dome 2.1.2 Pole Mounting Before you start: Prepare one bracket and three hoops, and fix the hoops on the...
  • Page 17 Figure 2-5 Prepare accessory Steps: Lock the hoops and bracket on a pole, and route the cables through the vertical mounting bracket. Then fix the mounting bracket on the bracket attached on the pole before. Figure 2-6 Route the cables Use the wrench to fix the head cover on the bracket.
  • Page 18 Figure 2-7 Fix the head cover Hook the speed dome to the bracket with supplied safety rope. Figure 2-8 Use safety rope...

  • Page 19: Pendant Mounting

    Connect the cables, and align the speed dome with the head cover, using wrench to tighten the screws on the head cover. Figure 2-9 Finish the installation 2.1.3 Pendant Mounting Steps: Drill four holes on the ceiling to match those on the pendant mount bracket.
  • Page 20 Route the cables through the bracket, then align the base plate to the holes and fix it to the ceiling with four screws. Figure 2-11 Route the cables Use the wrench to fix the head cover on the bracket. Figure 2-12 Fix the head cover...
  • Page 21 Hook the speed dome to the bracket with supplied safety rope. Figure 2-13 Use safe rope Connect the cables, and align the speed dome with the head cover, using wrench to tighten the screws on the head cover. Figure 2-14 Finish the installation...

  • Page 22: Setting The Ip-Camera Over The Lan

    3 Setting the IP-Camera over the LAN Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, contact your dealer or the nearest service center for help.

  • Page 23: Activating The Camera

    Activation via Web Browser and Activation via Grundig IP-Finder Tool are supported. We will take activation via Grundig IP-Finder Tool and Activation via Web Browser as examples to introduce the camera activation.

  • Page 24: Activation Via Grundig Ip-Finder Tool

    5. Click OK to save the password and enter the live view interface. Activation via Grundig IP-Finder Tool The Grundig IP-Finder Tool is used for detecting the online device and activating the camera. Get the Grundig Finder Tool from the supplied disk or the official website and install the software according to the prompts.
  • Page 25 Grundig IP-Finder Interface Note: The software supports activating the camera in batch. Refer to the user manual of Grundig IP-Finder for details. 3. Create and input the new password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly...

  • Page 26: Modifying The Ip Address

    To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your Use the Grundig IP-Finder Tool to search and change the IP address of the device. We take modifying the IP Address via Grundig IP-Finder as an example to introduce the IP address modification.
  • Page 27 Modify the IP Address 4. Input the admin password and click Update to activate your IP address modification. The batch IP address modification is supported by the Grundig IP- Finder. Please refer to the User Manual of Grundig IP-Finder for details.

  • Page 28: Accessing Via Web Browser

    4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8 and above version, Apple Safari 16 and above version, Mozilla Firefox 52.0 and above version and Google Chrome 57.0 and above version.
  • Page 29 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug- Note: You may have to close the web browser to finish the installation of the plug-in. Download Plug-in 6.

  • Page 30: Initializing The Memory Card

    Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
