- Page 1 SDR-ICS-43 User Manual VERSION 0.28 3116 West Vanowen St. Burbank, CA 91505 Tel: 818-840-8131 Fax: 818-840-8138 www.adrftech.com Advanced RF Technologies, Inc.
- Page 2 Information in this document is subject to change without notice. Advanced RF Technologies, Inc. 1996-2017. All rights reserved. · Please send comments to: E-Mail: info@adrftech.com Phone: (818) 840-8131 (800) 313-9345 Fax: (818) 840-8138 · Address: Advanced RF Technologies, Inc. Attention: Technical Publications Department 3116 Vanowen St.
- Page 3 REVISION HISTORY Version Author Descriptions Date ADRF Initial Release 11/07/ 2017 CK ,CHO Update 05/14/ 2018 0.21 CK ,CHO Update, Model name changed 07/10/ 2018 0.22 CK ,CHO Update 07/18/ 2018 0.23 CK ,CHO AWS Bandwidth Change 08/31/ 2018 0.25...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction..............................8 Highlights.............................. 8 Parts List ............................... 9 Repeater Quick View........................... 10 Warnings and Hazards......................... 10 Overview ..............................15 LED ..............................15 Host/Remote Switch ........................... 15 Ethernet Port ............................15 2.3.1 AC Power ............................. 16 2.3.2 Back Up Battery Port ........................16 RF Ports............................... - Page 5 5.4.4 Remote Ethernet Settings......................32 5.4.5 Auto Installation........................... 33 5.4.6 Date & Time ..........................34 5.4.7 Band Selection ..........................35 System ..............................35 5.5.1 System: Account........................... 35 System: Account- Account Management ................35 5.5.1.1 System: Account- New Account................... 35 5.5.1.2 System: Account- Change Password ..................
- Page 6 Figure 2-3 AC Input Port..........................16 Figure 2-5 Battery Backup Port........................16 Figure 2-6 RF port............................17 Figure 4-1 SDR-ICS-43 Wall Mount ........................ 20 Figure 4-2 Ground Cable Connection......................20 Figure 4-3 RF Repeater Oscillation......................... 21 Figure 4-4 Line of Sight to the eNode-B(or BTS)..................... 22 Figure 5-1 Login page............................
- Page 7 The following is a list of abbreviations and terms used throughout this document. Abbreviation/Term Definition Automatic Gain Control Automatic Level Control AROMS ADRF’ Repeater Operation and Management System Bi-Directional Amplifier Base Transceiver Station CDMA Code Division Multiple Access Crest Factor Reduction...
-
Page 8: Introduction
1. INTRODUCTION The SDR-ICS-43 is an over-the-air high power repeater. SDR-ICS-43 supports SMR800+Cellular, PCS, BRS-TDLTE band. Highlights · Active ICS (Interference Cancellation System) · Band Selectable · Digital filtering with sharp roll-off (>50dBc @ ± 1 MHz from sub-band edge) ·... -
Page 9: Parts List
Parts List Table 1-1 Parts List Label Quantity Description SDR-ICS-43 SDR-ICS-43 Wall Mount Bracket Mounting Bracket Template AC Power Cable Ethernet Cable (Crossover) Anchor Bolt Ground Cable Documentation CD* Optional SDR-ICS-43 Modem Package Modem Modem Connection Cable 19inch Chassis Ethernet Cable (Crossover) Figure 1-1 SDR-ICS-43 Repeater Parts List * CD includes: User Manual, Quick-Start Guide, and Troubleshooting Guide... -
Page 10: Repeater Quick View
Repeater Quick View Modem DONOR CPL-20dB DUPLEXER Backup Battery Port LNA0 AC Input Port LNA1 Modem Antenna Port SERVER CPL-40dB Server Duplexer Host/Remote Switch Warnings and Hazards Advanced RF Technologies, Inc. - Page 11 WARNING! ELECTRIC SHOCK Opening the SDR-ICS-43 could result in electric shock and may cause severe injury. WARNING! EXPOSURE TO RF Working with the repeater while in operation, may expose the technician to RF electromagnetic fields that exceed FCC rules for human exposure. Visit the FCC website at www.fcc.gov/oet/rfsafety to learn more about the effects of exposure to RF electromagnetic fields.
- Page 12 Lithium Battery: CAUTION. RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO INSTRUCTIONS. Ethernet Instructions: This equipment is for indoor use only. All cabling should be limited to inside the building. FCC Part 15 Class A NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 13 ◈LABEL WARNING◈ Regulatory Warning Statement FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
- Page 14 WARNING! Hot surface RSS-131 Warning Statement The passband gain shall not exceed the nominal gain by more than 1.0 dB. The 20 dB bandwidth shall not exceed the nominal bandwidth that is stated by the manufacturer. Outside of the 20 dB bandwidth, the gain shall not exceed the gain at the 20 dB point.
-
Page 15: Overview
2. OVERVIEW SDR-ICS-43 has an LED in the Lower left corner as shown in figure below. Figure 2-1 Table 2-1 RF Module LED Specifications LED Indicator Specifications Service Green System is Normal Orange Soft Fail Hard Fail Host/Remote Switch Figure 2-2 Host/Remote Switch The Host/Remote Switch allows the user to switch the default Repeater IP, Subnet Mask, and Gateway of the LOCAL port of the repeater to an alternative setup. -
Page 16: Ac Power
Figure 2-3 Ethernet Port · LAN0 – The Local port can be used to communicate directly with the SDR-ICS-43 using a RJ-45 crossover cable or can also be used to connect the SDR-ICS-43 to an external modem box or the optional internal Digi Transport WR-21. -
Page 17: Rf Ports
If an ADRF-BBU is utilized, connect the ADRF-BBU to the SDR-ICS-43 via the external battery port. (WARNING: The circuit switch on the ADRF-BBU must be set to OFF before connecting the ADRF-BBU to the SDR- ICS-43 to prevent damage to the repeater or the ADRF-BBU and personal injury.) Note: Please contact ADRF Technical Support for assistance if you are unfamiliar with the installation procedure of our battery box. -
Page 18: Alarms
3. ALARMS Message Board Alarms and Notification Table 3-1 Message Board Alarms and Notification Parameters Remark AC Fail Power supply is not operating within specs DC Fail Power supply is not operating within specs Fan[1/2] Fail System has detected an issue with the fan1 and fan2 Temperature Module is above the normal operating temperature Current... -
Page 19: Alarms
Alarms Table 3-2 Alarms Threshold Parameters Remark AC Fail Power supply is not operating within specs. (4 seconds) DC Fail Power supply is not operating within specs. (4 seconds) Fan1, Fan2 Fail System has detected an issue with each fan. (4 seconds) Module is above the normal operating temperature. -
Page 20: Installation
4. INSTALLATION Installation Procedures 4.1.1 Wall Mount Procedure · Verify that the SDR-ICS-43 and mounting hole are in good condition · Place the SDR-ICS-43 mounting template up against the wall and mark of mount holes · Mount the SDR-ICS-43 to wall use the six (6) mounting hole on the wall mount bracket ·... -
Page 21: Antenna Separation/Isolation
Antenna Separation/Isolation Separation between the antennas is necessary to prevent oscillation. Oscillation occurs when the signal entering the system continually reenters, due to the lack of separation between the donor and server antennas. In other words, the signal is being fed back into the system. This creates a constant amplification of the same signal. As a result, the noise level rises above the signal level. -
Page 22: Line Of Sight
WARNING: Inserting a CW signal into the SDR-ICS-43 when ICS is enabled will cause the system to generate a false alarm. The false alarm will cause the system to go into a shutdown state. If a CW signal needs to be injected into the repeater for testing purposes, the ICS routine must be turned off. -
Page 23: Sdr-Ics-43 Web-Gui Setup
If you are not the Administrator, please type in your assigned username & password which you should have received from the Administrator. The default username and password for the General User is adrf & adrf, respectively. The default Administrator login is admin & admin, respectively. -
Page 24: Status Tab
Status Tab Figure 5-2 Status Tab 5.2.1 Band Figure 5-3 Band Display 5.2.2 Power & Gain This section displays the Input, Gain, and Output for both downlink and uplink. Advanced RF Technologies, Inc. -
Page 25: Alarm
Figure 5-4 Power & Gain Display · Input [dBm] – Displays the in-band Downlink/Uplink signal level. The system will display “--.-“when the input level is < -90 dBm. · Gain [dB] User Set: Displays the amount of gain that user set. ALC: Displays the amount of gain that is attenuated by ALC function. -
Page 26: Install, Power And Modem Status
Figure 5-6 Message Board · Log File: Downloads the system Log File (events and alarms) to your computer 5.2.5 Install, Power and modem Status Figure 5-7 Install, Power and modem Status · Installation: Displays whether or not the installation routine has been run (Not Installed or Installed) ·... -
Page 27: Figure 5-8 Repeater Info / Repeater Location / Technical Support / Installer Contact Info
· Repeater Location: Displays the address where the repeater is installed · Technical Support: Displays ADRF’s Technical Support contact information · Installer Contact Info: Displays the installer’s name, phone and e-mail address Note: Once successfully logged in, the repeater model name and the site/cascade ID will be displayed on the top of all the windows (except for the Main Window). -
Page 28: Control Tab
Control Tab Figure 5-9 Control page 5.3.1 General Setting Figure 5-10 General Setting · ICS ON: Enables or disables the Interference Cancellation System (ICS) · ILC ON: Enables or disables the Interference Level Control (ILC) · Downlink HPA ON: Enables or disables the DL HPA (High Power Amplifier) ·... -
Page 29: System
WARNING: Inserting a CW signal into the SDR-ICS-43 when ICS is enabled will cause the system to generate a false alarm. The false alarm will cause the system to go into a shutdown state. If a CW signal needs to be injected into the repeater for testing purposes, the ICS routine must be turned off. -
Page 30: Ics Control
Figure 5-15 Gain Control Setting · Downlink Gain/Uplink Gain: Allows the UL gain to be adjusted manually when ALC is OFF · DL Output ALC Level: Prevents the output power from exceeding the specified value · DL Output ALC Offset: When the incoming signal level increases, the system will not adjust the attenuation levels until the delta reaches the level specified ·... -
Page 31: Install Tab
· VSWR ON: Allows the user to enable/disable the VSWR alarm check Install Tab 5.4.1 Install Figure 5-18 Install page Advanced RF Technologies, Inc. -
Page 32: Snmp
5.4.2 SNMP Figure 5-19 SNMP The SNMP section allows you to specify the Site ID, Description and Manager IP. The Site-ID is the code that is used to identify a particular module. The Description is separate field for user. The Manager IP field is where the user inputs the IP address of the NOC system that is being used to monitor the SNMP traps. -
Page 33: Auto Installation
Figure 5-21 Remote Ethernet Settings 5.4.5 Auto Installation Figure 5-22 Auto Installation The Auto Installation routine can be run by clicking on the Install button. The Auto Installation routine runs basic system checks to ensure proper functionality. Advanced RF Technologies, Inc. -
Page 34: Date & Time
Repeater Location Info / Repeater Installer Info This section allows the user to specify the address of the repeater and also the information of the installer. Figure 5-23 Repeater Location Info / Repeater Installer Info 5.4.6 Date & Time This section allows the user to specify the current date and time. Figure 5-24 Date &... -
Page 35: Band Selection
5.4.7 Band Selection Figure 5-25 Band Selection Band selection allows the user specify the desired frequncies. System The System tab allows the user to perform firmware updates, upload closeout packages, view any changes to the system, backup existing configuration, and add/remove user accounts, and change the login credentials of the Administrator. -
Page 36: System: Account- Change Password
Figure 5-27 System: Account- New Account 5.5.1.3 System: Account- Change Password The Change Password section allows the current user who is logged into the system to change their login credentials. Figure 5-28 System: Account- Change Password Advanced RF Technologies, Inc. -
Page 37: System- Closeout Package
5.5.2 System- Closeout Package The closeout package section will allow the user to upload documents to the module. The maximum file size for each upload is limited to 10 MB. The total amount of space available for uploading document is 100 MB. Please do not use this section as the primary storage location of your documents. -
Page 38: System: Update
5.5.4 System: Update · To perform a firmware update, click on the System tab and the following screen will appear. Figure 5-32 System – Update · Update File Upload Click on the Browse… button and locate the firmware file Click on the Upload button to the firmware file upload. Once the firmware upload is complete, File List will update. -
Page 39: Help
Click the Save button to perform the backup. To restore the settings to your system, select the file and click the Restore button. To download the file, select it and click the download button. To delete a file, select it and click the Delete button. -
Page 40: Warranty And Repair Policy
· Do not operate the repeater with the antennas in extremely close proximity to one another as this may cause damage to the repeater. · Do not change the parameters unless instructed to do so by an authorized supervisor. · Do not move the repeater unless instructed to do so by an authorized supervisor. -
Page 41: Specifications
8. SPECIFICATIONS Electrical Specifications SDR-ICS-43_Sprint Specifications Specifications SDR-ICS-43-S8C SDR-ICS-43-P SDR-ICS-43-BT Comments Downlink 862~894MHz 1930~1995MHz 2496~2690MHZ Frequency 817~849MHz 1850~1915MHz 2496~2690MHZ Uplink Band Selection per Filter LTE- 20 MHz LTE- 20 MHz TD-LTE- 20 MHz (ICS Mode) Band Selection per Filter LTE- 20 MHz LTE- 20 MHz TD-LTE-20 MHz (SDR Mode) -
Page 42: Sdr-Ics-43_Verizon Specifications
SDR-ICS-43_Verizon Specifications SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- Specifications Comments 728~746MH 746~757MH 862~894MH 1930~1995 2110~2155 Downlink Frequency 698~716MH 776~787MH 817~849MH 1850~1915 1710~1755 Uplink Band Selection per Filter LTE- 10 MHz LTE- 10 MHz LTE- 20 MHz LTE- 20 MHz LTE- 20 MHz (ICS Mode) Band Selection per Filter LTE- 10 MHz... - Page 43 SDR-ICS-43_7F/7FN/ WCS Specifications Specifications SDR-ICS-43-7F SDR-ICS-43-7FN SDR-ICS-43-W Comments Downlink 728~757MHz 758~768MHz 2350~2360MHz Frequency 698~716MHz 788~798MHz 2305~2315MHz Uplink 776~787MHz Band Selection per Filter LTE- 10 MHz LTE- 10 MHz LTE- 10 MHz (ICS Mode) Band Selection per Filter LTE- 10 MHz...
-
Page 44: Mechanical Specifications
Mechanical Specifications Parameters Specifications Comments Dimension of chassis 19.0 X 10.50 X 17.00 Inches 482 X 266.5 X 430 mm (W*H*D) 7L/7U/S8C/P/A/BT/W 4.18 X 10.34 X 17.73 Inches 106 X 262.5 X 450 mm (W*H*D) Dimension of repeater 7F/7FN 5.28 X 10.34 X 17.73 Inches 134 X 262.5 X 450 mm (W*H*D) 7L/7U/S8C/P/A/BT/W 30.5 lbs... -
Page 45: Appendix
9. APPENDIX Shutdown Retry Logic The function of the built-in shutdown routine is to protect the repeater from any further damage from a hard- fail that the system may be experiencing. Within 5 seconds of a hard-fail alarm being detected, the repeater will start the shutdown routine. The repeater will shut down by powering of the HPAs (high-powered amplifiers) for 30 seconds.
