Summary of Contents for ADRF SDR-ICS-43-6
- Page 1 SDR-ICS-43-6 User Manual VERSION 0.29 3116 West Vanowen St. Burbank, CA 91505 Tel: 818-840-8131 Fax: 818-840-8138 www.adrftech.com Advanced RF Technologies, Inc.
- Page 2 Information in this document is subject to change without notice. Advanced RF Technologies, Inc. 1996-2017. All rights reserved. Please send comments to: E-Mail: info@adrftech.com Phone: (818) 840-8131 (800) 313-9345 Fax: (818) 840-8138 Address: Advanced RF Technologies, Inc. Attention: Technical Publications Department 3116 Vanowen St.
- Page 3 REVISION HISTORY Version Author Descriptions Date ADRF Initial Release 11/07/ 2017 CK ,CHO Update 05/14/ 2018 0.21 CK ,CHO Update, Model name changed 07/10/ 2018 0.22 CK ,CHO Update 07/18/ 2018 0.23 CK ,CHO AWS Bandwidth Change 08/31/ 2018 0.25...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction ................................ 9 Highlights ..............................9 Parts List..............................10 Repeater Quick View ..........................11 Warnings and Hazards ..........................12 Overview ................................16 LED ................................16 Host/Remote Switch ..........................16 Ethernet Port ............................. 16 2.3.1 AC Power ............................17 2.3.2 Back Up Battery Port .......................... - Page 5 5.4.4 Remote Ethernet Settings ........................33 5.4.5 Auto Installation ..........................34 5.4.6 Date & Time ............................35 5.4.7 Band Selection ............................ 36 System ............................... 36 5.5.1 System: Account ..........................36 System: Account- Account Management ................. 36 5.5.1.1 System: Account- New Account ....................36 5.5.1.2 System: Account- Change Password ..................
- Page 6 FIGURES Figure 1-1 SDR-ICS-43 Repeater Parts List ......................10 Figure 2-1 LED ..............................16 Figure 2-2 Host/Remote Switch ........................... 16 Figure 2-3 AC Input Port ............................17 Figure 2-5 Battery Backup Port ..........................17 Figure 2-6 RF port ..............................18 Figure 4-1 SDR-ICS-43 Wall Mount ........................
- Page 7 TABLES Table 1-1 Parts List ............................. 10 Table 2-1 RF Module LED Specifications ......................16 Table 3-1 Message Board Alarms and Notification .................... 19 Table 3-2 Alarms Threshold ..........................20 Table 8-1 Electrical Specifications .......................... Advanced RF Technologies, Inc.
- Page 8 The following is a list of abbreviations and terms used throughout this document. Abbreviation/Term Definition Automatic Gain Control Automatic Level Control AROMS ADRF’ Repeater Operation and Management System Bi-Directional Amplifier Base Transceiver Station CDMA Code Division Multiple Access Crest Factor Reduction...
-
Page 9: Introduction
1. INTRODUCTION SDR-ICS-43-6 is an over-the-air high power repeater. SDR-ICS-43-6 supports 600, 700, SMR800+Cellular, PCS, AWS, WCS, BRS-TDLTE band. Highlights Active ICS (Interference Cancellation System) Band Selectable Digital filtering with sharp roll-off (>50dBc @ ± 1 MHz from sub-band edge) ... -
Page 10: Parts List
Ethernet Cable (Crossover) Anchor Bolt Ground Cable Documentation CD* Optional SDR-ICS-43-6 Modem Package Modem Modem Connection Cable 19inch Chassis Ethernet Cable (Crossover) Figure 1-1 SDR-ICS-43-6 Repeater Parts List * CD includes: User Manual, Quick-Start Guide, and Troubleshooting Guide Advanced RF Technologies, Inc. -
Page 11: Repeater Quick View
Repeater Quick View SDR-ICS-43-X SDR-ICS-43- Modem DONOR CPL-20dB DUPLEXER CPL(-20dB) DONOR Backup LAN0 BATTERY Battery Port LNA0 AC Input Port AC IN LNA1 Modem LAN1 Antenna Port MODEM CPL(-40dB) SERVER CPL-40dB SERVICE Server Duplexer HOST SERVER Host/Remote Switch REMOTE Advanced RF Technologies, Inc. -
Page 12: Warnings And Hazards
Warnings and Hazards WARNING! ELECTRIC SHOCK Opening the SDR-ICS-43-6 could result in electric shock and may cause severe injury. WARNING! EXPOSURE TO RF Working with the repeater while in operation, may expose the technician to RF electromagnetic fields that exceed FCC rules for human exposure. Visit the FCC website at www.fcc.gov/oet/rfsafety... - Page 13 Lithium Battery: CAUTION. RISK OF EXPLOSION IF BATTERY IS REPLACED BY INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO INSTRUCTIONS. Ethernet Instructions: This equipment is for indoor use only. All cabling should be limited to inside the building. FCC Part 15 Class A NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 14 ◈LABEL WARNING◈ Regulatory Warning Statement FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of UL:35cm, DL:180 cm between the radiator and your body.
- Page 15 RSS-GEN, Sec. 7.1.2 – (detachable antennas) This radio transmitter (identify the device by certification number, or model number if Category II)has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
-
Page 16: Overview
2. OVERVIEW SDR-ICS-43-6 has an LED in the Lower left corner as shown in figure below. Figure 2-1 Table 2-1 RF Module LED Specifications LED Indicator Specifications Service Green System is Normal Orange Soft Fail Hard Fail Host/Remote Switch Figure 2-2... -
Page 17: Ac Power
LAN0 – The Local port can be used to communicate directly with the SDR-ICS-43-6 using a RJ-45 crossover cable or can also be used to connect the SDR-ICS-43-6 to an external modem box or the optional internal Digi Transport WR-21. -
Page 18: Rf Ports
The SDR-ICS-43-6 can be connected to an ADRF-BBU (ADRF Battery Backup) to provide power during a power failure. If an ADRF-BBU is utilized, connect the ADRF-BBU to the SDR-ICS-43 via the external battery port. (WARNING: The circuit switch on the ADRF-BBU must be set to OFF before connecting the ADRF-BBU to SDR-ICS- 43-6 to prevent damage to the repeater or the ADRF-BBU and personal injury.) -
Page 19: Alarms
3. ALARMS Message Board Alarms and Notification Table 3-1 Message Board Alarms and Notification Parameters Remark AC Fail Power supply is not operating within specs DC Fail Power supply is not operating within specs Fan[1/2] Fail System has detected an issue with the fan1 and fan2 Temperature Module is above the normal operating temperature Current... -
Page 20: Alarms
Alarms Table 3-2 Alarms Threshold Parameters Remark AC Fail Power supply is not operating within specs. (4 seconds) DC Fail Power supply is not operating within specs. (4 seconds) Fan1, Fan2 Fail System has detected an issue with each fan. (4 seconds) Module is above the normal operating temperature. -
Page 21: Installation
Verify that the SDR-ICS-43-6 and mounting hole are in good condition Place the SDR-ICS-43-6 mounting template up against the wall and mark of mount holes Mount the SDR-ICS-43-6 to wall use the six (6) mounting hole on the wall mount bracket Connect the GND cable ... -
Page 22: Antenna Separation/Isolation
For example, if the gain of the repeater is 50 dB, then an isolation of 55dB or greater is required. In the same manner, because the SDR-ICS-43-6 has a maximum gain of 95dB in case of SDR-ICS-43-6, it requires isolation of at least 100dB. -
Page 23: Line Of Sight
WARNING: Inserting a CW signal into the SDR-ICS-43-6 when ICS is enabled will cause the system to generate a false alarm. The false alarm will cause the system to go into a shutdown state. If a CW signal needs to be injected into the repeater for testing purposes, the ICS routine must be turned off. -
Page 24: Sdr-Ics-43 Web-Gui Setup
5. SDR-ICS-43-6 WEB-GUI SETUP The Web-GUI allows the user to communicate with the repeater either locally or remotely. To connect to the repeater locally, you will need a laptop with an Ethernet port and a RJ-45 crossover cable. To connect to the repeater remotely, you will need to have an active internet connection and the repeater must have either an internal modem or an external modem box connected to the repeater. -
Page 25: Status Tab
Status Tab Figure 5-2 Status Tab 5.2.1 Band Figure 5-3 Band Display 5.2.2 Power & Gain This section displays the Input, Gain, and Output for both downlink and uplink. Advanced RF Technologies, Inc. -
Page 26: Alarm
Figure 5-4 Power & Gain Display Input [dBm] – Displays the in-band Downlink/Uplink signal level. The system will display “--.-“when the input level is < -90 dBm. Gain [dB] User Set: Displays the amount of gain that user set. ALC: Displays the amount of gain that is attenuated by ALC function. -
Page 27: Install, Power And Modem Status
Figure 5-6 Message Board Log File: Downloads the system Log File (events and alarms) to your computer 5.2.5 Install, Power and modem Status Figure 5-7 Install, Power and modem Status Installation: Displays whether or not the installation routine has been run (Not Installed or Installed) ... -
Page 28: Figure 5-8 Repeater Info / Repeater Location / Technical Support / Installer Contact Info
Repeater Location: Displays the address where the repeater is installed Technical Support: Displays ADRF’s Technical Support contact information Installer Contact Info: Displays the installer’s name, phone and e-mail address Note: Once successfully logged in, the repeater model name and the site/cascade ID will be displayed on the top of all the windows (except for the Main Window). -
Page 29: Control Tab
Control Tab Figure 5-9 Control page 5.3.1 General Setting Figure 5-10 General Setting ICS ON: Enables or disables the Interference Cancellation System (ICS) ILC ON: Enables or disables the Interference Level Control (ILC) Downlink HPA ON: Enables or disables the DL HPA (High Power Amplifier) ... -
Page 30: System
WARNING: Inserting a CW signal into the SDR-ICS-43 when ICS is enabled will cause the system to generate a false alarm. The false alarm will cause the system to go into a shutdown state. If a CW signal needs to be injected into the repeater for testing purposes, the ICS routine must be turned off. -
Page 31: Ics Control
Figure 5-15 Gain Control Setting Downlink Gain/Uplink Gain: Allows the UL gain to be adjusted manually when ALC is OFF DL Output ALC Level: Prevents the output power from exceeding the specified value DL Output ALC Offset: When the incoming signal level increases, the system will not adjust the attenuation levels until the delta reaches the level specified ... -
Page 32: Install Tab
VSWR ON: Allows the user to enable/disable the VSWR alarm check Install Tab 5.4.1 Install Figure 5-18 Install page Advanced RF Technologies, Inc. -
Page 33: Snmp
5.4.2 SNMP Figure 5-19 SNMP The SNMP section allows you to specify the Site ID, Description and Manager IP. The Site-ID is the code that is used to identify a particular module. The Description is separate field for user. The Manager IP field is where the user inputs the IP address of the NOC system that is being used to monitor the SNMP traps. -
Page 34: Auto Installation
Figure 5-21 Remote Ethernet Settings 5.4.5 Auto Installation Figure 5-22 Auto Installation The Auto Installation routine can be run by clicking on the Install button. The Auto Installation routine runs basic system checks to ensure proper functionality. Advanced RF Technologies, Inc. -
Page 35: Date & Time
Repeater Location Info / Repeater Installer Info This section allows the user to specify the address of the repeater and also the information of the installer. Figure 5-23 Repeater Location Info / Repeater Installer Info 5.4.6 Date & Time This section allows the user to specify the current date and time. Figure 5-24 Date &... -
Page 36: Band Selection
5.4.7 Band Selection Figure 5-25 Band Selection Band selection allows the user specify the desired frequncies. System The System tab allows the user to perform firmware updates, upload closeout packages, view any changes to the system, backup existing configuration, and add/remove user accounts, and change the login credentials of the Administrator. -
Page 37: System: Account- Change Password
Figure 5-27 System: Account- New Account 5.5.1.3 System: Account- Change Password The Change Password section allows the current user who is logged into the system to change their login credentials. Figure 5-28 System: Account- Change Password Advanced RF Technologies, Inc. -
Page 38: System- Closeout Package
5.5.2 System- Closeout Package The closeout package section will allow the user to upload documents to the module. The maximum file size for each upload is limited to 10 MB. The total amount of space available for uploading document is 100 MB. Please do not use this section as the primary storage location of your documents. -
Page 39: System: Update
5.5.4 System: Update To perform a firmware update, click on the System tab and the following screen will appear. Figure 5-32 System – Update Update File Upload Click on the Browse… button and locate the firmware file ... -
Page 40: Help
Click the Save button to perform the backup. To restore the settings to your system, select the file and click the Restore button. To download the file, select it and click the download button. To delete a file, select it and click the Delete button. -
Page 41: Warranty And Repair Policy
Do not operate the repeater with the antennas in extremely close proximity to one another as this may cause damage to the repeater. Do not change the parameters unless instructed to do so by an authorized supervisor. Do not move the repeater unless instructed to do so by an authorized supervisor. -
Page 42: Specifications
8. SPECIFICATIONS Electrical Specifications SDR-ICS-43_Sprint Specifications Specifications SDR-ICS-43-S8C SDR-ICS-43-P SDR-ICS-43-BT Comments Downlink 862~894MHz 1930~1995MHz 2496~2690MHZ Frequency 817~849MHz 1850~1915MHz 2496~2690MHZ Uplink Band Selection per Filter LTE- 20 MHz LTE- 20 MHz TD-LTE- 20 MHz (ICS Mode) Band Selection per Filter LTE- 20 MHz LTE- 20 MHz TD-LTE-20 MHz (SDR Mode) -
Page 43: Sdr-Ics-43_Verizon Specifications
SDR-ICS-43_Verizon Specifications SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- SDR-ICS-43- Specifications Comments 728~746MH 746~757MH 862~894MH 1930~1995 2110~2155 Downlink Frequency 698~716MH 776~787MH 817~849MH 1850~1915 1710~1755 Uplink Band Selection per Filter LTE- 10 MHz LTE- 10 MHz LTE- 20 MHz LTE- 20 MHz LTE- 20 MHz (ICS Mode) Band Selection per Filter LTE- 10 MHz... - Page 44 SDR-ICS-43_7F/7FN/W_Specifications Specifications SDR-ICS-43-7F SDR-ICS-43-7FN SDR-ICS-43-W Comments Downlink 728~757MHz 758~768MHz 2350~2360MHz Frequency 698~716MHz 788~798MHz 2305~2315MHz Uplink 776~787MHz Band Selection per Filter LTE- 10 MHz LTE- 10 MHz LTE- 10 MHz (ICS Mode) Band Selection per Filter LTE- 10 MHz LTE- 10 MHz LTE- 10 MHz (SDR Mode) Simultaneous...
- Page 45 SDR-ICS-43-6_Specifications Specifications SDR-ICS-43-6 Comments Downlink 617~652MHz Frequency 663~698MHz Uplink Band Selection per Filter LTE- 20 MHz (ICS Mode) 5GNR-20MHz Band Selection per Filter LTE- 20 MHz (SDR Mode) 5GNR-20MHz Simultaneous Mode selection Filter Support Full Band ±1.5dB Gain Flatness Each Band ±1.5dB...
-
Page 46: Mechanical Specifications
Mechanical Specifications Parameters Specifications Comments Dimension of chassis 19.0 X 10.50 X 17.00 Inches 482 X 266.5 X 430 mm (W*H*D) 600/7L/7U/S8C/P/A/BT/W 4.18 X 10.34 X 17.73 Inches 106 X 262.5 X 450 mm (W*H*D) Dimension of repeater 7F/7FN 5.28 X 10.34 X 17.73 Inches 134 X 262.5 X 450 mm (W*H*D) 600/7L/7U/S8C/P/A/BT/W 30.5 lbs... -
Page 47: Appendix
9. APPENDIX Shutdown Retry Logic The function of the built-in shutdown routine is to protect the repeater from any further damage from a hard- fail that the system may be experiencing. Within 5 seconds of a hard-fail alarm being detected, the repeater will start the shutdown routine. The repeater will shut down by powering of the HPAs (high-powered amplifiers) for 30 seconds.
