- Page 1 INSTALLATION MANUAL Natura ™ Series White Matte Undermount Bathroom Sink KSU-8MW www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 30, 2017...
- Page 2 Thank you for purchasing Kraus We would like to take this opportunity to thank you for your business with Kraus USA. It is our sincere hope that you are completely satisfied with your experience. We welcome any questions or comments you may have, and will be glad to assist you in the future.
-
Page 3: Prior To Installation
Prior to Installation: • Make sure that you have all necessary parts by checking the parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Inspect the sink prior to installation to make sure it has not been cracked or chipped during shipping •... - Page 4 Tape Measure Pencil Scissors Screwdriver NOTE: Specialized tools may be necessary to install Kraus Undermount sinks with countertop materials other than wood, marble, or granite Parts List (Included) • Cut-Out Template • Mounting Hardware • Cleaning Sponge • Buffing Paper...
- Page 5 Dimensions 21.7” 1.7” 21.7”L x 14.2”W x 4.8”H 21.7” 1.7” 14.2” 14.2” 4.8” 4.8” Top View Bottom View Front View Side View...
- Page 6 1. Cut Paper Template • Use scissors to cut along the inside line of the paper template Finished Wall 2” (50.8mm Suggested) 2.5” (63.5mm Suggested) Clip Location minimum of 4.5” (114.3mm all for faucet placement ce before cutting) Rim of Lavatory 490mm 19.3"...
- Page 7 Rim of Lavatory Cut Along This Line 17.7” (450mm) Step3 3. Cut Countertop • Cut the countertop opening by carefully following the pencil line traced from the template Please use the appropriate saw that best fits your countertop NOTE: material...
- Page 8 4. Install Anchors • Flip countertop over and place on a foam pad for protection. Use cutout template to mark the anchor placement on the countertop. Drill 5/16” diameter x 3/8” deep hole in countertop • Place epoxy in the drilled hole. Insert brass nut anchors into the drilled hole and wait until the epoxy cures NOTE: •...
- Page 9 Clip Location Rim of Lavatory Cut Along This Line 5. Install Sink 14.25” (362mm) • Use a bead of clear silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the opening in the countertop. Place sink over cutout hole and press firmly •...
- Page 10 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 11 COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.com Like & Follow KrausUSA Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance www.kraususa.com...
