- Page 1 I N S TA L L AT I O N MA N UA L Single Lever Pull-Down Kitchen Faucet KPF-1630 www.kraususa.com I toll free: 1.800.775.0703 I © 2013-2014 Kraus USA Inc.
- Page 2 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help.
-
Page 3: Prior To Installation
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement • Turn off the cold and hot water at the angle stops and turn on the old faucet to release any built up pressure •... - Page 4 Diagram and Parts List...
- Page 5 Diagram and Parts List Tools you will need 1. Spray Head 2. Faucet Body Adjustable Wrench 3. Deck Plate Assembly A. Deck Plate B. Base Plate 4. Mounting Hardware A. Rubber & Metal Washer B. Mounting Nut Silicone Sealant C. Mounting Screws (optional) 5.
- Page 6 Faucet Installation Procedure 8-3/8” 8-3/8” (211.4mm) (211.4mm) 4” 4” (100.5mm) (100.5mm) MAX 2" MAX 2" MAX51mm MAX51mm Installer Tip: Shut off main water supply before installing new faucet...
- Page 7 STEP1 STEP 2A STEP 2B Step 1: Remove mounting hardware Remove the mounting screws (4C), mounting nut (4B), and rubber & metal washer (4A) from the mounting pipe STEP 2A STEP 2B Step 2A: Faucet installation - with deck plate For three-hole installation: STEP 4 STEP 5...
- Page 8 STEP 2B STEP 3 Step 2B: Faucet installation - without deck plate For single-hole installation: Deck plate (3A), base plate (3B), and silicone sealant are NOT required STEP 3 Step 3: Install faucet and mounting hardware Insert faucet body (2) into hole in countertop or deck plate assembly (3).
- Page 9 STEP 4 STEP 5 Step 4: Secure mounting hardware Adjust direction of faucet body (2) so that handle is on right side of faucet. Tighten mounting nut (4B) until snug. Tighten mounting screws (4C) to nut with a Phillips screwdriver until snug STEP 5 STEP 6 Step 5: Attach spray hose and counterweight...
- Page 10 STEP 6 STEP 7 Step 6: Connect waterlines Connect waterlines (not included) to hot and cold copper lines (8). Connect waterlines (not included) to angle stops. Tighten both ends of waterlines with a wrench until snug. Turn on hot and cold angle stops and check for leaks STEP 4 STEP 5...
-
Page 11: Replacement Parts
Replacement Parts a. Aerator b. Spray Head Check Valve Spray Hose Hose Guide Hexagon Nut Handle Button Set Screw Metal Handle Cartridge Cover Locking Nut 10. Cartridge 11. Cartridge Housing Cold 12. Deck Plate Water Water 13. Base Plate 14. Rubber & Metal Washer 15. -
Page 12: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under faucet Locking nut has come Remove button located... - Page 13 Maintenance - Cartridge Replacement Step 1: Remove button located at the top of the handle. Loosen the set screw with a hex wrench. Remove the handle and unscrew cartridge cover by hand Step 2: Unscrew the locking nut with an adjustable wrench.
- Page 14 Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 15 Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance www.kraususa.com...
