- Page 1 INSTALLATION MANUAL Natura ™ Series White Matte Semi-Recessed Bathroom Sink KSR-9MW www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 30, 2017...
- Page 2 Thank you for purchasing Kraus We would like to take this opportunity to thank you for your business with Kraus USA. It is our sincere hope that you are completely satisfied with your experience. We welcome any questions or comments you may have, and will be glad to assist you in the future.
-
Page 3: Prior To Installation
Inspect the sink prior to installation to make sure that it has not been cracked or chipped during shipping • Use the cut-out template provided by Kraus to cut the opening in your countertop • Observe all plumbing and building codes according to your state requirements •... - Page 4 Jig Saw Putty Knife Tape Measure Pencil Scissors NOTE: Specialized tools may be necessary to install Kraus Semi-Recessed sinks with countertop materials other than wood, marble, or granite Parts List (Included) • Cut-Out Template • Cleaning Sponge • Buffing Paper...
- Page 5 Dimensions 14.6”L x 15”W x 4.8”H 14.6” 14.6” 15” 15” 1.7” 1.7” 4.8” 4.8” Top View Bottom View Front View Side View...
- Page 6 1. Cut Paper Template Finished Wall 2” (50.8mm Suggested) • Use scissors to cut along the inside line of the paper template 2.5” (63.5mm Suggested) Model No. KSR-9MW Allow a minimum of 4.5” (114.3mm from wall for faucet placement Rim of Lavatory clearnace before cutting) Cut Along This Line 344mm...
- Page 7 Step3 3. Cut Countertop • Cut the countertop opening by carefully following the pencil line traced from the template NOTE: Please use the appropriate saw that best fits your countertop material...
- Page 8 4. Install Sink 13.4” (340mm) • Check the alignment of the sink to the opening in the countertop. Use a bead of clear silicone (or preferred adhesive) around the underside of the sink • Carefully insert the sink in place, align, and press firmly •...
- Page 9 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 10 COMMERCIAL WARRANTY Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.com Like & Follow KrausUSA Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance www.kraususa.com...
