USER MANUAL Table of Contents Safety Information……………………………………...………………3 Specifications………………………………………...…………………4 Main Power Connection…………………………...…………………..5 DMX-512 Connection……………………………..…………………...5 Size and Weight………………………………………………………..6 Gobo’s and Colors……………………………………………………..7 Main Control Menu……………..…………………………………..….8 Rigging the Fixture……………………………………………………..9 DMX Profile...................10 Cleaning & Maintenance...............14 Parts List..................14... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Specifications Part Numbers Fixture Lamp Flight Case 1210 - MS1 150W LED CAS-1210-4 Quad Road Case Mechanical Specifications Pan: 540° 8/16 Bit Tilt: 270° 8/16 Bit 3phase Motors DMX Connectors: 3 and 5-pin XLR connectors Power Connectors: Power Con Type In/Out Thermal: Maximum ambient temperature 110°... -
Page 5: Main Power Connection
120 Ohm resistor between the (-) and the (+) signal into a 3 or 5 pin XLR plug and plug it in to the last fixture on the signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite dealer (P-DMX-T). -
Page 6: Size And Weight
Size and Weight 7.5” 11.8” 3.75” 4” 18.75” 10.75” 4” 10.75” 9” Size 11.8” x 9” x 18.75” Packaged Size 14” x 12.5” x 23” Weight 24.5lb Gross 26lb... -
Page 7: Gobo's And Colors
Gobo’s and Color Colors 1 Red 5 Magenta 2 Yellow 6 Orange 3 Blue 7 Purple/UV 4 Green Animation Effect Gobo’s (non removable) -
Page 8: Main Control Menu
Display Control Main Control DMX Yes Mode 17Ch The control board on the fixture base is your interface to access and control all the functions on the unit. It’s LCD display gives you a code Enter Invert view of the options and functions. The following will explain each func- tion and its options. -
Page 9: Rigging The Fixture
Calibration Main Menu DMX Address Fixture Calibration Manual Warning this function is for trained factory technicians! Information Password Calibration Fixture Reset Pan Fine Tilt Display Tilt Fine P/T Speed Fixture Reset Main Menu DMX Address Fixture Fixture Reset Manual Lets you reset motor function on the fixture Information Motor Reset Calibration... -
Page 10: Dmx Profile
DMX Profile MS1 17Ch Mode DMX Ch Function Description Value Init Value 0-255 Pan Fine Pan Fine 0-255 Tilt Tilt 0-255 Tilt Fine Tilt Fine 0-255 P/T Speed Pan and Tilt Speed (fast to slow) 0-255 Closed Strobe (slow to fast) -
Page 11: Open
Open Gobo 1 10-19 Gobo 2 20-29 Gobo 3 30-39 Gobo 4 40-49 Gobo 5 50-59 Gobo Gobo 6 60-69 Gobo 1 Bounce (slow to fast) 70-79 Gobo 2 Bounce (slow to fast) 80-89 Gobo 3 Bounce (slow to fast) 90-99 Gobo 4 Bounce (slow to fast) 100-109... -
Page 12: Closed
MS1 21Ch Mode DMX Ch Function Description Value Init Value 0-255 Pan Fine Pan Fine 0-255 Tilt Tilt 0-255 Tilt Fine Tilt Fine 0-255 P/T Speed Pan and Tilt Speed (fast to slow) 0-255 Closed Strobe (slow to fast) 4-103... -
Page 13: No Function
Open Gobo 1 10-19 Gobo 2 20-29 Gobo 3 30-39 Gobo 4 40-49 Gobo 5 50-59 Gobo Gobo 6 60-69 Gobo 1 Bounce (slow to fast) 70-79 Gobo 2 Bounce (slow to fast) 80-89 Gobo 3 Bounce (slow to fast) 90-99 Gobo 4 Bounce (slow to fast) 100-109... -
Page 14: Cleaning & Maintenance
Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 15 Specifications in this manual are subject to change. Manual Version Please Visit www.mega.lighting for the most up to date manual version Document Date Fixture Software Notes Version 11/06/2019 V1.1 Mega-Lite 18668 Highway 16N Helotes, TX 78023 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
