Colour Television
Colour Television
Owner's Manual
HLT-2310 / 3010
Please read this manual carefully before operating your set.
Retain it for future reference.
See the label attached on the back cover and quote this infor-
mation to your dealer when you require service.
P/NO : MAN04HY0002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HLT-3010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai HLT-3010

Summary of Contents for Hyundai HLT-3010

  • Page 1 Colour Television Colour Television Owner’s Manual HLT-2310 / 3010 Please read this manual carefully before operating your set. Retain it for future reference. See the label attached on the back cover and quote this infor- mation to your dealer when you require service. P/NO : MAN04HY0002...
  • Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICE- ABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 3 Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire haz- ards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference.
  • Page 4 14. Outdoor Antenna Grounding a fire or electric shock. Never spill liquid of any kind on the product. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some pro- 19.

  • Page 5: Table Of Contents

    Warnings AVL (Auto Volume Leveler) Stereo/Dual/NICAM reception Safety Instructions Setting up TV stations 22-23 Contents Memorizing the Channels with Auto Add/Delete Channels with Manual Location and function of controls Fine Tuning Adjustment Remote control handset Favorite Channels Setup Battery installation Front panel Time Menu 24-25...
  • Page 6 - All the functions can be controlled with the remote control handset. - Some functions can also be adjusted with the buttons on the front panel of the set. - Before you use the remote control handset, please install the batteries. POWER MUTE switches the set on from standby or off to...
  • Page 7 - Your remote control handset is powered by two AAA type batteries. To insert batteries, turn the remote Put the two batteries into the compart- Replace the cover. control handset over and remove the ment observing battery polarity. battery cover. To avoid damage from possible bat- tery leakage, remove the batteries if you do not plan to use the remote con-...
  • Page 8 1. MAIN POWER switches the set on or off. (Programme Up/Down) selects a programme or a menu item. switches the set on from standby. (Volume Down/Up) adjusts the volume. INPUT INPUT MENU MENU SELECT SELECT adjusts menu settings. 4. MENU selects a menu.
  • Page 9 AUDIO AUDIO RS-232C INPUT RS-232C INPUT RGB INPUT RGB INPUT AUDIO INPUT AUDIO INPUT DVI INPUT DVI INPUT VIDEO VIDEO AUDIO AUDIO VIDEO VIDEO S-VIDEO S-VIDEO ANT. IN . IN AC INPUT AC INPUT AUDIO AUDIO COMPONENT COMPONENT INPUT INPUT AUDIO INPUT AUDIO INPUT (CONTROL/SER...
  • Page 10 Power Location This set operates on an AC mains supply, the voltage is as Position your set so that no bright light or sunlight falls indicated on the label on the back cover. Never apply DC directly onto the screen. Care should be taken not to power to the set.

  • Page 11: Connecting To An Inside Antenna Setup

    Connecting to an Inside Antenna Setup - Typical wall antenna jack used in apartment buildings, connect the antenna cable as shown below. - Typical wall antenna jack used in apartment buildings, connect the antenna cable as shown below. (Use the correct type of antenna cable for the type of wall antenna jack.) (Use the correct type of antenna cable for the type of wall antenna jack.) Turn clockwise to tighten.

  • Page 12: Vcr Setup

    VCR Setup - In Video mode, TV automatically reverts to TV mode if the fcr button or flashbk buttons are pressed. VIDEO AUDIO VIDEO S-VIDEO ANT. IN AC INPUT AUDIO Connection 1 Set VCR switch to 3 or 4 and then tune TV to the same channel num- ber.

  • Page 13: External A/V Source Setup

    External A/V Source Setup Connections Connect the audio/video output jacks on the external A/V equipment to VIDEO VIDEO AUDIO AUDIO S-VIDEO S-VIDEO AC INPUT AC INPUT VIDEO VIDEO AUDIO AUDIO ANT. IN . IN the corresponding input jacks on the TV. When connecting the TV to A A V2 V2 A A V1 V1 external A/V equipment, match the jack colors (Video = yellow, Audio...

  • Page 14: Dtv Setup

    DTV Setup - To watch digitally broadcast programs, purchase and connect a dig- ital set-top box. AUDIO AUDIO RS-232C INPUT RS-232C INPUT VIDEO VIDEO AUDIO AUDIO COMPONENT COMPONENT INPUT INPUT (CONTROL/SER (CONTROL/SERVICE) VICE) AUDIO INPUT AUDIO INPUT (480i/480p/720p/1080i) (480i/480p/720p/1080i) Connections A A V2 V2 Connect the digital set-top box video outputs to the COMPONENT (Y, PB, PR) jacks and connect the digital set-top box audio outputs...

  • Page 15: Volume Adjustment

    On and Off Programme selection On screen language selection (option) Press the main power button to switch You can select a programme Press the MENU button and then use the set on. number with the or NUM- button to select the SPECIAL menu. BER buttons.
  • Page 16 - The dialogue between you and your set takes place on screen with an operator menu. The buttons required for the operating steps are also displayed. Press the MENU but- Change the setting of an item in Press the button and Press the button to dis- ton and then use...

  • Page 17: Psm (Picture Status Memory)

    PSM (Picture Status Memory) Manual Picture Control Press the MENU Press the MENU button and Repeatedly press the MENU but- Press the button and ton to return to normal TV viewing. button and then use then use button to then use button button to select the PICTURE menu.

  • Page 18: Picture Format

    Picture format You can watch TV in various picture formats; 16:9, 4:3, Zoom, Panorama. Repeatedly press the ARC button to select your desired picture format. 1. Press the ARC button to select a desired picture format. • Each press of ARC button changes the screen display as shown below. •...

  • Page 19: Ssm (Sound Status Memory)

    SSM (Sound Status Memory) Press the MENU button and then Sound Frequency Adjustment You can also recall a desired sound Flat Speech Movie Music button to select the a. Press the button in User User ) with SSM button on the remote SOUND menu.

  • Page 20: Balance

    Balance AVL (Auto Volume Leveler) Press the MENU button and then use button to Press the MENU button and then use button to select the SOUND menu. select the SOUND menu. Press the button and then use button to select the Press the button and then use button to select...

  • Page 21: Stereo/Dual/Nicam Reception

    Stereo/Dual/NICAM reception Language selection for dual language broadcast In AV mode, you can select output sound for the left and right loudspeakers. If a programme received in two languages (dual language), Repeatedly press the I/II button to select the sound output. you can switch to DUAL I DUAL II...

  • Page 22: Memorizing The Channels With Auto

    Memorizing the Channels with Auto Add/Delete Channels with Manual - For Auto to work, the programming source must be con- - You can manually include or erase individual channels. nected to the TV and the TV must be receiving program- ming signals either over-the-air or from a cable-type ser- vice provider.

  • Page 23: Fine Tuning Adjustment

    Fine Tuning Adjustment Favorite Channels Setup - This function adjusts the pictures stability and condition - Favorite Channel lets you quickly tune in up to 5 chan- when it is poor. nels of your choice without having to wait for the TV to scan through all the in-between channels.
  • Page 24 Clock On/Off Time The off timer automatically switches the set to standby at the preset time. You must set the time correctly before using on/off time function. Press the MENU button and then D D / E E button to select the TIME menu. Press the MENU button and then Press the button and then...

  • Page 25: Time Menu

    Auto sleep Sleep timer If you select on the Auto Sleep menu, the set will You don’t have to remember to switch the set off before automatically switch itself to standby mode approximately you go to sleep. The sleep timer automatically switches ten minutes after a TV station stops broadcasting.

  • Page 26: Csm (Colour Status Memory)

    CSM (Colour Status Memory) Caption Caption/Text To initialize values (reset to default Use the CC button repeatedly to select Press the menu button and then Captions. settings), select the Normal option. D D / E E button to select the SPE- CIAL menu.

  • Page 27: Lock Menu Options

    Lock Menu Options Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcast station. The default setting is to allow all programs to be viewed. Viewing can be blocked by the type of program and by the categories chosen to be blocked.

  • Page 28: Lock Menu Setup

    Lock Menu Setup 1. Press the MENU button and then use D D / E E button to select the LOCK menu. Then, press the button. • If Lock is already set, enter the password requested. • The TV is set with the initial password “0-0-0-0”. 2.

  • Page 29: Pc Setup

    PC Setup You can adjust horizontal/vertical position, clock, phase, and Auto-configure auto-configure, reset as you prefer. This function is for the automatic adjustment of the screen position, clock and phase. The displayed image will disappear Press the MENU button and then button to select for a few seconds while the Auto-configuration is in progress.

  • Page 30: Watching Pip

    - PIP lets you view 2 different inputs (sources) on your monitor screen at the same time. One source will be large, and the other source will show a smaller inset image. Watching PIP Moving the PIP Press the PIP button to show the sub picture. Press the PIP POSITION button.

  • Page 31: Swapping The Pip

    Swapping the PIP Programme scan Selecting a Input Signal Source for the PIP Press the SWAP button to exchange This function enables you to search all the stored stations on 4 or 12 sub pic- the main and sub pictures. Use the PIP INPUT button to tures and see your favourite station by select the input source for the sub...
  • Page 32 - Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system) and con- trol the set’s functions externally. How to connect external control equipment Type of connector; D-Sub 9-pin male Pin name <...
  • Page 33 Set ID Command Reference List Press the MENU button and then use button to COMMAND COMMAND DATA (Hexadecimal) select the SPECIAL menu. 01. Power 0 ~ 1 02. Input Select 0 ~ 7 Press the button and then use button to 03.
  • Page 34 01. Power (Command2 : a) Transmission / Receiving Protocol G To control Power On/Off of the set. Transmission Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [k][a][ ][Set ID][ ][Data][Cr] * [Command 1] Data 0 : Power Off 1 : Power On * [Command 2] : To control PDP set.
  • Page 35 03. Aspect Ratio (Command2 : q) (Main picture format) 06. Volume Control (Command2 : i) G To adjust volume. G To adjust the screen format. You can also adjust volume with the volume buttons You can also adjust the screen format using the ARC on remote control handset.
  • Page 36 12. Remote Control Lock Mode (Command2 : p) 09. Colour (Command2 : f) G To lock the remote control and front panel controls on the G To adjust the screen color. You can also adjust color in the PICTURE menu. Transmission Transmission [k][f][ ][Set ID][ ][Data][Cr]...
  • Page 37 15. Balance (Command2 : j) * Real data mapping 1 * Real data mapping 2 G To adjust balance. 0 : Step 0 0 : -10 You can also adjust balance in the SOUND menu. 5 : -9 Transmission A : Step 10 (SET ID 10) A : -8 [k][j][ ][Set ID][ ][Data][Cr] F : Step 15 (SET ID 15)
  • Page 38 20. Auto Sleep (Command2 : n) 23. Auto Configure (Command2 : ~) G If there is no input signal, the set turn off automatically G To adjust picture position and minimize image shaking after 10 minutes. automatically. It works only in RGB (PC) mode. Transmission Transmission [k][n][ ][Set ID][ ][Data][Cr]...
  • Page 39 26. Programme selection (Command2 : %) G To select a programme for the main picture. Transmission [k][%][ ][Set ID][ ][Data][Cr] Data 0 : Ch Up 1 : Ch Down Acknowledgement [%][ ][Set ID][ ][OK][Data][x] 27. Programme Number input (Command2 : $) To select a programme.
  • Page 40 RGB Mode / DVI Mode Horizontal Vertical MODE Resolution Frequency (Hz) Frequency (KHz) 70.08 31.469 720X400 37.927 85.03 31.500 60.00 37.500 67.00 640X480 72.80 37.861 Note: 37.500 75.00 a. If the set is cold, there may be a small “flicker” when the set is 43.269 85.00 switched on.
  • Page 42 NOTE...
  • Page 43 Symptoms No picture, no sound Sound OK, poor picture Picture OK, poor sound Picture blurred Lines or streaks in picture Poor reception on some channels No colour Poor colour Remote control does not work Incorrect position Vertical bars or stripes on background Horizontal noise Signal Cable message appears Check these items and try to adjust these...
