Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Color
Mitsubishi Eclipse Cross (Smart Key) 2019
HS CAN 1 High
Yellow
HS CAN 1 Low
Brown
HS CAN 2 High
Yellow
HS CAN 2 Low
Red
Door Lock
Gray
12V
White
Ignition
Red
Parking Lights (right)
Gray
Parking Lights (left)
White
Starter
Lt.Blue
PTS 1
White
PTS 2
Violet
Trunk/Hatch Release
Lt. Blue (rear handle switch)
Locating components in the vehicle
Fuse Box
located in driver's dash
C-418
C-417
11
Pin
Polarity
Location
6
Data
OBDII diagnostic connector, under driver dash.
14
Data
OBDII diagnostic connector, under driver dash.
17
Data
C-417 connector, located at fuse box in driver dash.
16
Data
C-417 connector, located at fuse box in driver dash.
28
(-)
C-417 connector, located at fuse box in driver dash.
2
(+)
C-410 connector, located at fuse box in driver dash.
2
(+)
C-402 connector, located at fuse box in driver dash.
3
(+)
C-418 connector, located at fuse box in driver dash.
6
(+)
C-418 connector, located at fuse box in driver dash.
9
(+)
C-420 connector, located at fuse box in driver dash.
2
(+)
Engine Start/Stop Switch, at Push-To-Start button.
4
(-)
Engine Start/Stop Switch, at Push-To-Start button.
18
(-)
Dash Fuse Box
Connector Information
Color
Black
Black
White
White
White
Black
White
White
White
White
White
White
White
Directed Digital Solutions MIT2
© 2020-02-05 Directed. All rights reserved.
Pins
Ref.
16
A
16
A
36
B
36
B
36
B
2
C
8
D
13
E
13
E
13
F
12
G
12
G
22
H
